Description
The TPE-1620WSF switch from TRENDNET is a managed Layer L2/L3 device with 20 Gigabit Ethernet RJ-45 ports, 16 of which support PoE, plus 4 SFP28 ports for high-speed fibre links. It includes power supply via a 3-pin terminal block and a 1U black metal housing, designed for rack installations. Its management covers web administration, cloud access, and event and user operation logging, with MIB II support. It offers Quality of Service (QoS), link aggregation, and VLAN support for up to 296 virtual networks, including advanced features such as MAC-based VLAN, private VLAN, protocol-based VLAN, and voice VLAN.
Specifications
Management features
- Switch type: Managed
- Switch layer: L2/L3
- Quality of Service (QoS) support: Yes
- Web-based management: Yes
- Cloud-managed: Yes
- System event log: Yes
- User operation log: Yes
- MIB support: MIB II
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 20
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- Gigabit Ethernet (copper) ports quantity: 16
- SFP28 ports quantity: 4
- Power connector: Terminal block (3-pin)
Network
- Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3
- 10G support: No
- Copper ethernet cabling technology: 1000BASE-TX
- Port mirroring: Yes
- Full duplex: Yes
- IP routing: Yes
- Policy-based routing: Yes
- Flow control support: Yes
- Link aggregation: Yes
- Rate limiting: Yes
- Auto MDI/MDI-X: Yes
- Ethernet LAN data rates: 10,100,480,800,1000 Mbit/s
- Auto-negotiation: Yes
- Active link detection: Yes
- VLAN support: Yes
- Virtual LAN features: MAC address-based VLAN, Private VLAN, Protocol-based VLAN, Voice VLAN
- Number of VLANs: 296
Data transmission
- Switching capacity: 32 Gbit/s
- Throughput: 23.8 Mpps
- MAC address table: 16000 entries
- Static route: Yes
- Jumbo frames support: Yes
Security
- DHCP features: DHCP client, DHCP server
- Access Control List (ACL): Yes
- IGMP snooping: Yes
- Security algorithms: 802.1x RADIUS, SSL/TLS
- SSH/SSL support: Yes
- IP-MAC-Port binding: Yes
- Password protection: Yes
- MAC address entries: Dynamic MAC address entries, Static MAC address entries
Multicast features
- Multicast support: Yes
Protocols
- Management protocols: HTTP/HTTPS (SSL v2/3 TLS), Web-based GUI, SNMP v1/v2c/v3, LLDP, RMON v1
Design
- Rack mounting: Yes
- Form factor: 1U
- Product colour: Black
- LED indicators: Yes
Performance
- Mean time between failures (MTBF): 192382 h
Power
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
- Power consumption (max): 460 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): Yes
- Power over Ethernet (PoE) type supported: Active PoE
- Power over Ethernet plus (PoE+) ports quantity: 16
- Power over Ethernet (PoE) power per port: 30 W
- Total Power over Ethernet (PoE) budget: 370 W
Operational conditions
- Operating temperature (T-T): -5 - 50 °C
- Operating relative humidity (H-H): 10 - 90%
Weight & dimensions
- Width: 250 mm
- Depth: 44 mm
- Height: 440 mm
- Weight: 3.89 kg
Packaging content
- Cables included: AC
- Quick start guide: Yes
- Rack mount kit: Yes
Certificates
- Certification: CE, FCC, UL
Logistics data
- Harmonized System (HS) code: 85176990
