Description
The Trendnet TI-PG262 switch, in black, is an unmanaged switch with 24 RJ-45 Gigabit Ethernet (10/100/1000) ports and PoE support, designed to simplify connectivity in office or small business networks. It has 2 SFP slots for optional fibre links and a switching capacity of 52 Gbit/s, with a forwarding rate of 38.6 Mpps. It includes features such as auto-negotiation, half-duplex mode, support for jumbo frames of 9000 bytes, port mirroring and IEEE 802.3af/at standards for Power over Ethernet. Its wall-mounting design and LED indicators facilitate installation and basic monitoring of network traffic.
Specifications
Management features
- Switch type: Unmanaged
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 24
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- SFP module slots quantity: 2
Network
- Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
- 10G support: Yes
- Port mirroring: Yes
- Half duplex: Yes
- Auto-negotiation: Yes
Data transmission
- Switching capacity: 52 Gbit/s
- Forwarding rate: 38.6 Mpps
- MAC address table: 8000 entries
- Store-and-forward: Yes
- Jumbo frames support: Yes
- Jumbo frames: 9000
Design
- Product colour: Black
- LED indicators: Yes
- Wall mountable: Yes
- DIN rail mounting: Yes
Performance
- Mean time between failures (MTBF): 503149 h
Power
- Power source: DC/PoE
- DC input voltage: 48 - 56 V
- Power consumption (max): 5.76 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): Yes
- Power over Ethernet (PoE) type supported: PoE+
- Power over Ethernet plus (PoE+) ports quantity: 16
- Power over Ethernet (PoE) power per port: 30 W
- Total Power over Ethernet (PoE) budget: 480 W
Operational conditions
- Operating temperature (T-T): -40 - 75 °C
Weight & dimensions
- Width: 155 mm
- Depth: 120 mm
- Height: 78 mm
- Weight: 900 g
Certificates
- Certification: CE FCC LVD
