Name: TP-Link Omada 300Mbps Wireless N Ceiling Mount Access Point
Brand: TP-LINK
Price: 34.28 USD
Availability: InStock

TP-Link Omada 300Mbps Wireless N Ceiling Mount Access Point

$34.28

$34.28 without VAT

TP-Link Omada 300Mbps Wireless N Ceiling Mount Access Point. More info

Amount

Brand: TP-LINK

SKU: 93530 PRC: 372575 EAN: 6935364091637 PN: EAP110 V4

Description

Specifications

Features

2.4 GHz: Yes
5 GHz: No
6 GHz: No
Maximum data transfer rate: 300 Mbit/s
Maximum data transfer rate (2.4 GHz): 300 Mbit/s
Ethernet LAN data rates: 10, 100 Mbit/s
Frequency band: 2.4 - 2.4835 GHz
Networking standards: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x
Cabling technology: 10/100Base-T(X)
Wi-Fi Multimedia (WMM)/(WME): Yes
VLAN support: Yes
Virtual LAN features: VLAN mapping
Rate limiting: Yes
Wireless isolation: Yes
Quality of Service (QoS) support: Yes
Transmitting power (CE): 19 dBm
Transmitting power (FCC): 21 dBm
Receiver sensitivity: 300M: -71dBm@10% PER 150M: -75dBm@10% PER 54M: -78dBm@10% PER 11M: -93dBm@8% PER 6M: -92dBm@10% PER 1M: -96dBm@8% PER

Security

Security algorithms: 64-bit WEP, 128-bit WEP, 152-bit WEP, HTTPS, SNMP, SNMPv2, SSH, WPA, WPA-PSK, WPA2-Enterprise, WPA2-PSK
MAC address filtering: Yes
Service Set Identifier (SSID) features: Multiple SSIDs
Number of SSID supported: 8
Access Control List (ACL): Yes

Management features

Web-based management: Yes
Syslog: Yes

Ports & interfaces

Ethernet LAN (RJ-45) ports: 1

Power

Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) type supported: Passive PoE
AC input voltage: 24 V
Power consumption (typical): 2.8 W

Design

Placement: Ceiling, Wall
Product colour: White
Reset button: Yes
LED indicators: Power

Antenna

Antenna type: Internal
Antenna direction type: Omni-directional
Antennas quantity: 2
Antenna gain level (max): 4 dBi

Certificates

Compliance certificates: Federal Communications Commission (FCC), CE, RoHS

Weight & dimensions

Width: 189.5 mm
Depth: 170.5 mm
Height: 29.7 mm

Packaging data

Package width: 246 mm
Package depth: 268 mm
Package height: 69 mm
Package weight: 720 g
Package type: Box

Packaging content

Quantity per pack: 1 pc(s)
PoE adapter included: Yes
Cables included: AC
Mounting kit: Yes
Quick start guide: Yes

Operational conditions

Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -40 - 70 °C
Storage relative humidity (H-H): 5 - 90%

Sustainability

Sustainability compliance: Yes

Logistics data

Harmonized System (HS) code: 85176990
