Thermaltake Toughpower GF A3 Snow 1050W - TT Premium Edition power supply unit 24-pin ATX ATX White
More info
Brand: THERMALTAKE
173,00 €Stock available: 0 units.
Unavailable
SKU:
102493
PRC:
460357
EAN:
4711475640191
PN:
ps-tpd-1050fnfage-n
Description
Thermaltake Toughpower GF A3 Snow 1050W power supply in a white finish, an ATX unit with a 24-pin main connector and a 12+4-pin PCI Express connector for modern graphics cards. It delivers a total power output of 1050 W, with a combined +12V output also of 1050 W and a maximum current of 87.5 A on that rail, along with active power factor correction. Its design incorporates protections against overcurrent, overvoltage, overvoltage, overheating, short circuit and undervoltage, with a hold-up time of 17 ms. This power supply accepts an input voltage of 100-240 V and a frequency of 50/60 Hz, with maximum currents of 20 A on the +3.3 V and +5 V rails, and 3 A on +5Vsb.
Specifications
Power
- Total power: 1050 W
- AC input voltage: 100 - 240 V
- AC input frequency: 50/60 Hz
- Input current: 16 A
- Power Factor Correction (PFC) type: Active
- Combined power (+3.3V): 100 W
- Combined power (+12V): 1050 W
- Combined power (+5V): 100 W
- Combined power (-12V): 3.6 W
- Combined power (+5Vsb): 15 W
- Max output current (+3.3V): 20 A
- Max output current (+12V): 87.5 A
- Max output current (+5V): 20 A
- Max output current (-12V): 0.3 A
- Max output current (+5Vsb): 3 A
- Hold time: 17 ms
- Power protection features: Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Ports & interfaces
- Motherboard power connector: 24-pin ATX
- Motherboard power cable length: 60 cm
- Number of SATA power connectors: 8
- SATA power cable length: 500, 650, 800, 950 mm
- Peripheral (Molex) power connectors (4-pin): 8
- Peripheral (Molex) power cable length: 500, 650, 800, 950 mm
- EPS power connector (4+4 pin): Yes
- PCI Express power connectors (6+2 pin): 5
- PCI Express power connectors (12+4 pin): 1
- CPU power connector (4+4 pin): Yes
- ATX Power connector (24-pin): Yes
- Floppy drive power connector: 1
- Floppy disk drive connector: Yes
- Floppy disk drive cable length: 15 cm
- Cabling type: Fully-Modular
Performance
- 80 PLUS certification: 80 PLUS Gold
- Purpose: PC
- Power supply unit (PSU) form factor: ATX
- ATX version: 3.0
Design
- Product colour: White
- Cooling type: Active
- Fan diameter: 12 cm
- Number of fans: 1 fan(s)
- Fan location: Top
- On/off switch: Yes
Operational conditions
- Operating temperature (T-T): 5 - 45 °C
- Storage temperature (T-T): -40 - 55 °C
- Operating relative humidity (H-H): 20 - 85%
- Storage relative humidity (H-H): 10 - 95%
Certificates
- Compliance certificates: BSMI, CB, CCC, CE, Federal Communications Commission (FCC), Low Voltage Directive (LVD), cTUVus, UKCA
Weight & dimensions
- Width: 150 mm
- Depth: 140 mm
- Height: 86 mm
Logistics data
- Warranty period: 10 year(s)
