Description
Specifications
Management features
- Switch type: Managed
- Switch layer: L3
- Quality of Service (QoS) support: Yes
- Web-based management: Yes
- ARP inspection: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 24
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- SFP module slots quantity: 4
- Console port: RJ-45
- Power connector: AC-in jack
Network
- Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.
- 10G support: No
- Port mirroring: Yes
- IP routing: Yes
- Ethernet LAN data rates: 10,100,1000 Mbit/s
- VLAN support: Yes
Data transmission
- Switching capacity: 56 Gbit/s
- Forwarding rate: 41.7 Mpps
- MAC address table: 16000 entries
- Jumbo frames support: Yes
- Jumbo frames: 10000
Security
- DHCP features: DHCP relay, DHCP snooping
- Access Control List (ACL): Yes
- IGMP snooping: Yes
- Security algorithms: 802.1x RADIUS
- MAC address filtering: Yes
Multicast features
- Multicast support: Yes
Protocols
- Management protocols: SNMP V1/V2/V3, Telnet, Console
- Multicast protocols: IGMP Snooping V1/V2/V3
Design
- Rack mounting: Yes
- Form factor: 1U
- Product colour: Grey
- LED indicators: Activity, Link, PoE, Power, System
- Wall mountable: Yes
- Number of fans: 2 fan(s)
Power
- Power supply included: Yes
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
- Power consumption (max): 432 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): Yes
- Power over Ethernet (PoE) ports quantity: 24
- Power over Ethernet (PoE) power per port: 30 W
- Total Power over Ethernet (PoE) budget: 370 W
Operational conditions
- Operating temperature (T-T): 0 - 45 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 10 - 90%
- Storage relative humidity (H-H): 5 - 90%
Weight & dimensions
- Width: 440 mm
- Depth: 284 mm
- Height: 44 mm
Certificates
- Certification: CCC, FCC, CE, RoHS
