Mars Gaming MPB550 power supply unit 550 W 20+4 pin ATX ATX Black

Not avaliable

More info

Brand: MARS GAMING
SKU: 85318 PRC: 293448 EAN: 4710562755428 PN: MPB550

Description

Specifications

Power

  • Total power: 550 W
  • AC input voltage: 200 - 240 V
  • AC input frequency: 50 - 60 Hz
  • Power Factor Correction (PFC) type: Active
  • Combined power (+3.3V): 100 W
  • Combined power (+12V): 480 W
  • Combined power (+5V): 100 W
  • Combined power (-12V): 3.6 W
  • Combined power (+5Vsb): 12.5 W
  • Max output current (+3.3V): 18 A
  • Max output current (+12V): 40 A
  • Max output current (+5V): 18 A
  • Max output current (-12V): 0.3 A
  • Max output current (+5Vsb): 2.5 A
  • Efficiency: 90%

Ports & interfaces

  • Motherboard power connector: 20+4 pin ATX
  • Number of SATA power connectors: 4
  • Number of PATA power connectors: 2
  • PCI Express power connectors (6+2 pin): 1
  • CPU power connector (4+4 pin): Yes
  • Cabling type: Non-Modular

Performance

  • 80 PLUS certification: 80 PLUS Bronze
  • Purpose: PC
  • Power supply unit (PSU) form factor: ATX
  • Noise level: 10 dB

Design

  • Product colour: Black
  • Cooling type: Active
  • Fan diameter: 12 cm
  • Number of fans: 1 fan(s)

Certificates

  • Compliance certificates: RoHS
  • Certification: ATX12V, Haswell Ready, CE

Weight & dimensions

  • Width: 150 mm
  • Depth: 145 mm
  • Height: 85 mm
  • Weight: 1.19 kg

Packaging data

  • Package width: 191 mm
  • Package depth: 91 mm
  • Package height: 263 mm
  • Package weight: 1.39 kg
  • Package type: Box
