Hewlett Packard Enterprise Aruba 6100 24G Class4 PoE 4SFP+ 370W Managed L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Black
Hewlett Packard Enterprise Aruba 6100 24G Class4 PoE 4SFP+ 370W, Managed, L3, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting, 1U.
More infoBrand: HEWLETT PACKARD ENTERPRISE
1,603,00 €Stock available: 0 units.
Unavailable
SKU:
89062
PRC:
333100
EAN:
190017348452
PN:
jl677a
Description
The Hewlett Packard Enterprise Aruba 6100 managed switch, in black, offers Gigabit Ethernet (10/100/1000) connectivity with 24 basic RJ-45 switching ports and 4 slots for SFP+ modules, plus a USB console port. Its L3 layer architecture and 128 Gbit/s switching capacity enable it to handle routing and network segmentation tasks reliably. It includes VLAN support, quality of service (QoS), flow control, port mirroring, link aggregation and spanning tree protocol, along with 10G support and Jumbo Frames. The MAC address table supports 8192 entries and its packet buffer reaches 12.38 MB, with a throughput of 95.2 Mpps. Its dimensions are 442 x 44 x 268 mm (width x height x depth) and its weight is 4.2 kg, in a 1U rack-mountable form factor.
Specifications
Management features
- Switch type: Managed
- Switch layer: L3
- Quality of Service (QoS) support: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 24
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- SFP+ module slots quantity: 4
- Console port: USB
Network
- Networking standards: IEEE 802.1D,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3at,IEEE
- 10G support: Yes
- Port mirroring: Yes
- Flow control support: Yes
- Link aggregation: Yes
- Spanning tree protocol: Yes
- VLAN support: Yes
Data transmission
- Switching capacity: 128 Gbit/s
- Throughput: 95.2 Mpps
- MAC address table: 8192 entries
- Latency (1 Gbps): 1.5 µs
- Latency (10 Gbps): 1.8 µs
- Jumbo frames support: Yes
- Packet buffer memory: 12.38 MB
Security
- DHCP features: DHCP client
- Access Control List (ACL): Yes
- IGMP snooping: Yes
- Authentication: MAC-based authentication
- Authentication type: RADIUS,TACACS+
Multicast features
- Multicast support: Yes
Design
- Rack mounting: Yes
- Stackable: Yes
- Form factor: 1U
- Product colour: Black
- Airflow direction: Side-to-side airflow
Performance
- Virtual stacking (units): 16
- Built-in processor: Yes
- Processor model: ARM Cortex-A9
- Processor frequency: 1016 MHz
- Memory type: DDR3-SDRAM
- Internal memory: 4096 MB
- Flash memory: 16 MB
Power
- Power supply included: Yes
- AC input voltage: 100 - 240 V
- AC input frequency: 50/60 Hz
- Power consumption (max): 32.7 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): Yes
- Total Power over Ethernet (PoE) budget: 370 W
Operational conditions
- Operating temperature (T-T): 0 - 45 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 15 - 95%
- Storage relative humidity (H-H): 15 - 90%
Weight & dimensions
- Width: 442 mm
- Depth: 268 mm
- Height: 44 mm
- Weight: 4.2 kg
