Name: D-Link 5-Port Gigabit PoE Smart Managed Switch with 1 PD port
Brand: D-LINK
Price: 73.32 USD
Availability: InStock

D-Link 5-Port Gigabit PoE Smart Managed Switch with 1 PD port

$73.32

$73.32 without VAT

D-Link 5-Port Gigabit PoE Smart Managed Switch with 1 PD port. More info

Amount

Brand: D-LINK

SKU: 87554 PRC: 314080 EAN: 790069453298 PN: DGS-1100-05PDV2

Description

Specifications

Management features

Switch type: Managed
Quality of Service (QoS) support: Yes
Web-based management: Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 5
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity: 5

Network

Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
10G support: No
Port mirroring: Yes
Full duplex: Yes
Half duplex: Yes
Flow control support: Yes
Broadcast storm control: Yes
Auto MDI/MDI-X: Yes
Head-of-line (HOL) blocking: Yes
Ethernet LAN data rates: 10000 Mbit/s
Auto-negotiation: Yes
VLAN support: Yes
Virtual LAN features: Management VLAN, Port-based VLAN, Tagged VLAN, Voice VLAN
Number of VLANs: 4094

Data transmission

Switching capacity: 10 Gbit/s
Forwarding rate: 7.44 Mpps
MAC address table: 2000 entries
Number of trunks: 1
Number of queues: 4
Jumbo frames: 9216
Packet buffer memory: 1 MB

Security

DHCP features: DHCP client
IGMP snooping: Yes
IGMP entries: 128
Static port security: Yes
SSH/SSL support: Yes
Queue scheduling algorithms: Weighted Round Robin (WRR)
MAC address entries: Static MAC address entries

Design

Rack mounting: No
Product colour: Black

Performance

Flash memory: 2 MB
Noise level: 0 dB
Fanless: Yes
Mean time between failures (MTBF): 2357475 h

Power

Power source: PoE
Power supply included: No
Power consumption (typical): 3.24 W
Power consumption (max): 24.08 W

Power over Ethernet (PoE)

Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) ports quantity: 2
Power over Ethernet (PoE) power per port: 18 W

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 0 - 90%
Storage relative humidity (H-H): 0 - 95%

Weight & dimensions

Width: 150 mm
Depth: 97 mm
Height: 28 mm
Weight: 380 g

Certificates

Compliance certificates: BSMI, CB, Federal Communications Commission (FCC), Low Voltage Directive (LVD), VCCI

Logistics data

Harmonized System (HS) code: 85176990
