Description
Corsair RMx Shift Series RM1200x SHIFT power supply, with a total power output of 1200 W and an ATX design in black, offers 90% efficiency to power demanding configurations. It features fully modular cabling and a 4+4-pin EPS connector, along with a 16-pin PCI Express connector, facilitating tidy installation. Its maximum output current on the +12V rail reaches 100 A, with protection against overcurrent, overvoltage, overheating, and short circuits. The motherboard power cable measures 61 cm, and it accepts input voltages from 100 to 240 V with a current of 7.5 to 15 A.
Specifications
Power
- Max output current (+12V): 100 A
- Max output current (+5V): 20 A
- Max output current (+5Vsb): 3 A
- Efficiency: 90%
- Power protection features: Over current, Over power, Over voltage, Overheating, Short circuit
- Total power: 1200 W
- AC input voltage: 100 - 240 V
- AC input frequency: 47 - 63 Hz
- Input current: 7.5 - 15 A
- Combined power (+3.3V): 150 W
- Combined power (+12V): 1200 W
- Combined power (+5V): 150 W
- Combined power (+5Vsb): 15 W
- Max output current (+3.3V): 20 A
Ports & interfaces
- Motherboard power connector: 24-pin ATX
- Motherboard power cable length: 61 cm
- Number of SATA power connectors: 16
- SATA power cable length: 455, 570, 685, 800 mm
- Peripheral (Molex) power connectors (4-pin): 8
- Peripheral (Molex) power cable length: 450, 550, 650, 750 mm
- EPS power connector (4+4 pin): Yes
- PCI Express power connectors (6+2 pin): 8
- PCI Express power connectors (16-pin): 1
- PCI Express power cable length: 75 cm
- Cabling type: Fully-Modular
Performance
- 80 PLUS certification: 80 PLUS Gold
- Purpose: PC/Server
- Power supply unit (PSU) form factor: ATX
- ATX version: 3.0
- EPS version: 2.92
- Bearing technology: FDB
- Mean time between failures (MTBF): 100000 h
Design
- Product colour: Black
- Cooling type: Active
- Fan diameter: 14 cm
- Number of fans: 1 fan(s)
- On/off switch: Yes
Packaging content
- Cables included: AC, DC
- Cable tie(s) included: Yes
Certificates
- Compliance certificates: Low Voltage Directive (LVD), RoHS, UKCA
Weight & dimensions
- Width: 150 mm
- Depth: 180 mm
- Height: 86 mm
- Weight: 2 kg
Technical details
- Sustainability compliance: Yes
Other features
- EPS cable length: 65 cm
- Screws included: Yes
