Cooler Master MWE 750 White 230V - V2 power supply unit 750 W 24-pin ATX ATX Black

Few units

Product 1 image

Product 2 image

Product 3 image

Product 4 image

Product 5 image

Product 6 image

Product 7 image

Product 8 image

Product 9 image

Cooler Master MWE 750 White 230V - V2 power supply unit 750 W 24-pin ATX ATX Black

94.00 €

77.69 € without VAT

Amount

Brand: COOLER MASTER

SKU: 102584 PRC: 460616 EAN: 4719512083208 PN: mpe-7501-acabw-eu

Description

Specifications

Power

Total power: 750 W
AC input voltage: 200 - 240 V
AC input frequency: 50 - 60 Hz
Input current: 6 A
Power Factor Correction (PFC) type: Active
Combined power (+3.3V): 120 W
Combined power (+12V): 744 W
Combined power (+5V): 120 W
Combined power (-12V): 3.6 W
Combined power (+5Vsb): 15 W
Max output current (+3.3V): 20 A
Max output current (+12V): 62 A
Max output current (+5V): 20 A
Max output current (-12V): 0.3 A
Max output current (+5Vsb): 3 A
Hold time: 14 ms
Efficiency: 85%
Power protection features: Over power, Over voltage, Overheating, Short circuit, Under voltage

Ports & interfaces

Motherboard power connector: 24-pin ATX
Motherboard power cable length: 50 cm
Number of SATA power connectors: 6
SATA power cable length: 400, 550, 700 mm
Peripheral (Molex) power connectors (4-pin): 3
Peripheral (Molex) power cable length: 400, 550, 700 mm
PCI Express power connectors (6+2 pin): 4
PCI Express power cable length: 60 cm
CPU power connector (4+4 pin): Yes
CPU power cable length: 67 cm
Cabling type: Non-Modular

Performance

80 PLUS certification: 80 PLUS
Supported motherboard form factors: ATX
Purpose: PC
Power supply unit (PSU) form factor: ATX
ATX version: 2.52
Bearing technology: HDB
Mean time between failures (MTBF): 100000 h

Design

Product colour: Black
Cooling type: Active
Fan diameter: 12 cm
Number of fans: 1 fan(s)
Fan speed: 0 - 2400 RPM

Operational conditions

Operating temperature (T-T): 0 - 40 °C

Certificates

Certification: CCC, CE, TUV-RH, EAC, RCM, cTUVus, FCC, BSMI, KC, CB

Weight & dimensions

Width: 150 mm
Depth: 140 mm
Height: 86 mm
Weight: 1.51 kg

Packaging data

Package width: 190 mm
Package depth: 245 mm
Package height: 110 mm
Package weight: 1.91 kg
Package type: Box

Logistics data

Products per pallet: 32 pc(s)
Master (outer) case width: 260 mm
Master (outer) case length: 570 mm
Master (outer) case height: 215 mm
Harmonized System (HS) code: 84733020
Products per master (outer) case: 5 pc(s)

Other features

Noise level (silent mode, <30%): 11.12 dB
Noise level (quiet mode, 50%): 20.3 dB
Noise level (full-load mode, 100%): 39.5 dB
