Description
Specifications
Management features
- Switch type: Managed
- Switch layer: L2/L3
- Quality of Service (QoS) support: Yes
- Web-based management: Yes
- Configuring Location Settings (CLI): Yes
- MIB support: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 48
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- Combo SFP ports quantity: 4
- Console port: RJ-45/USB Type-C
Network
- Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.
- Cable types supported: Cat5e
- Port mirroring: Yes
- Policy-based routing: Yes
- Link aggregation: Yes
- Broadcast storm control: Yes
- Rate limiting: Yes
- Spanning tree protocol: Yes
- Head-of-line (HOL) blocking: Yes
- QinQ implementation: Selective QinQ
- VLAN support: Yes
- Virtual LAN features: Private VLAN, Voice VLAN
Data transmission
- Switching capacity: 104 Gbit/s
- MAC address table: 16000 entries
- Number of queues: 8
- Static route: Yes
- Number of static routes: 990
- Jumbo frames support: Yes
- Jumbo frames: 9000
- Packet buffer memory: 3 MB
Security
- DHCP features: DHCP auto-config, DHCP client, DHCP relay, DHCP server, DHCP snooping
- Access Control List (ACL): Yes
- Access Control List (ACL) rules: 1024
- IGMP snooping: Yes
- IGMP proxy: Yes
- Security algorithms: HTTPS, SNMP, SNMPv2, SNMPv3, SSH, SSH-2
- SSH/SSL support: Yes
- Authentication: MAC-based authentication, Web-based authentication
- DoS attack prevention: Yes
- Authentication type: RADIUS, TACACS+
- Queue scheduling algorithms: Weighted Round Robin (WRR)
Multicast features
- Multicast support: Yes
Protocols
- GARP VLAN Registration Protocol (GVRP): Yes
- IPv4 & IPv6 features: ICMPv6, IPv6 SNMP, IPv6 SSH, IPv6 TFTP, IPv6 Telnet
Design
- Rack mounting: Yes
- Product colour: Grey
- Reset button: Yes
Performance
- Built-in processor: Yes
- Processor frequency: 1.4 MHz
- Memory type: DDR4-SDRAM
- Internal memory: 1000 MB
- Flash memory: 512 MB
- Noise level: 37.3 dB
- Plug and Play: Yes
- Mean time between failures (MTBF): 856329 h
Power
- Power source: AC
- AC input voltage: 100 - 220 V
- AC input frequency: 50/60 Hz
- Power consumption (typical): 43.93 W
- Power plug type: Type C
Power over Ethernet (PoE)
- Power over Ethernet (PoE): Yes
- Power over Ethernet (PoE) ports quantity: 48
- Total Power over Ethernet (PoE) budget: 375 W
Other features
- Packaging content: Switch, power cable, USB Type C cable and mounting hardware
Operational conditions
- Operating temperature (T-T): -5 - 50 °C
- Storage temperature (T-T): -25 - 70 °C
- Operating relative humidity (H-H): 10 - 90%
- Storage relative humidity (H-H): 10 - 90%
- Heat dissipation: 1542.3 BTU/h
Weight & dimensions
- Width: 350 mm
- Depth: 444.5 mm
- Height: 43.9 mm
- Weight: 5.43 kg
Packaging data
- Package width: 480.8 mm
- Package depth: 571.8 mm
- Package height: 95 mm
- Package weight: 7.01 kg
Certificates
- Certification: UL (UL 62368), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) Class A
Logistics data
- Country of origin: China
