Description
ATEN 2-port HDMI splitter with a maximum resolution of 3840 x 2160 pixels and a data transfer rate of up to 18 Gbit/s. The device offers three HDMI ports and one USB Type-C connector, with a frequency of 60 Hz. It is powered via USB at 5 V and 1 A, and includes LED indicators. HDCP 2.2 compatible, it reaches a maximum operating distance of 3 m. Its dimensions are 56.5 mm wide, 61 mm deep and 15.2 mm high, with a weight of 30 g.
Specifications
Ports & interfaces
- Keyboard port type: No
- Mouse port type: No
- Video port type: HDMI
- HDMI ports quantity: 3
- USB connector type: USB Type-C
Performance
- HD type: 4K Ultra HD
- Maximum resolution: 3840 x 2160 pixels
- Video bandwidth: 60 Hz
- Data transfer rate (max): 18 Gbit/s
- HDCP: Yes
- Maximum operating distance: 3 m
- HDCP version: 2.2
Design
- Rack mounting: No
- Product colour: Black
- LED indicators: Yes
Display
- Built-in display: No
Power
- Power source: USB
- Input voltage: 5 V
- Input current: 1 A
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -20 - 60 °C
- Operating relative humidity (H-H): 0 - 80%
- Storage relative humidity (H-H): 0 - 80%
Weight & dimensions
- Width: 56.5 mm
- Depth: 61 mm
- Height: 15.2 mm
- Weight: 30 g
Packaging content
- Cables included: USB Type-A to USB Type-C
- Quick installation guide: Yes
- Packaging content: 1x 2-Port True 4K HDMI Splitter 1x USB power cable (Type-C to Type-A) (1 m)
Logistics data
- Case or master carton dimensions (W x D x H): 213 x 320 x 156 mm
- Master (outer) case net weight: 1.2 kg
- Harmonized System (HS) code: 85437090
- Master (outer) case width: 213 mm
- Master (outer) case length: 320 mm
- Master (outer) case height: 156 mm
- Master (outer) case gross weight: 2.37 kg
- Master (outer) case volume: 0.38 cm³
- Products per master (outer) case: 20 pc(s)
- Country of origin: China
