Description
ATEN 8X8 True 4K HDMI Matrix Switch manages up to eight sources and eight displays with a transfer rate of 18 Gbit/s, supporting maximum resolutions of 4096 x 2160 pixels. It includes HDCP 2.2, HDR, 3D content and EDID compatibility, facilitating lossless signal distribution in professional setups. Its black metal casing occupies 1U of rack space and features control buttons, LED indicators, a power switch and an included remote control, along with a maximum pixel clock of 600 MHz.
Specifications
Features
- Product type: AV matrix switcher
- Data transfer rate: 18 Gbit/s
- Maximum pixel clock: 600 MHz
- Maximum resolution: 4096 x 2160 pixels
- HDCP: Yes
- HDCP version: 2.2
- 3D: Yes
- High Dynamic Range (HDR) supported: Yes
- Extended display identification data (EDID): Yes
- Supported resolutions: 4096 x 2160, 3840 x 2160, 1920 x 1200
Design
- Housing colour: Black
- Housing material: Metal
- Rack mounting: Yes
- Rack capacity: 1U
- Control type: Buttons
- On/off switch: Yes
- LED indicators: Yes
- Remote control included: Yes
Display
- Built-in display: Yes
Ports & interfaces
- HDMI input ports quantity: 8
- HDMI output ports quantity: 8
- Ethernet LAN (RJ-45) ports: 1
- RS-232 ports: 1
- Remote (IR) input: 1
Power
- Power consumption (max): 38.1 W
- Power consumption (typical): 37.8 W
- AC input voltage: 100-240 V
- AC input frequency: 50-60 Hz
- Input current: 1 A
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -20 - 60 °C
- Operating relative humidity (H-H): 0 - 80%
- Storage relative humidity (H-H): 0 - 80%
- Heat dissipation: 177 BTU/h
- Heat dissipation (max): 179 BTU/h
Logistics data
- Products per master (outer) case: 1 pc(s)
- Master (outer) case gross weight: 5.63 kg
- Master (outer) case length: 515 mm
- Master (outer) case width: 338 mm
- Master (outer) case height: 155 mm
- Master (outer) case net weight: 4.15 kg
- Harmonized System (HS) code: 85299097
Weight & dimensions
- Width: 432.4 mm
- Depth: 262.3 mm
- Height: 44 mm
- Weight: 4.15 kg
- Package width: 338 mm
- Package depth: 515 mm
- Package height: 155 mm
- Package weight: 5.63 kg
Packaging content
- Cables included: AC
- Rack mount kit: Yes
- Quick start guide: Yes
- IR receiver included: Yes
