- Product type: AV matrix switcher
- Data transfer rate: 18 Gbit/s
- Maximum pixel clock: 600 MHz
- Maximum resolution: 4096 x 2160 pixels
- HDCP: Yes
- HDCP version: 2.2
- 3D: Yes
- EDID management: Yes
Design
- Housing colour: Black
- Housing material: Metal
- Rack capacity: 1U
- Remote control included: Yes
Display
- Built-in display: Yes
Ports & interfaces
- HDMI input ports quantity: 4
- HDMI output ports quantity: 4
- RJ-45 input ports: 1
- RS-232 ports: 1
Power
- Power consumption (max): 17.8 W
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
- Input current: 1 A
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -20 - 60 °C
- Operating relative humidity (H-H): 0 - 80%
Logistics data
- Products per master (outer) case: 1 pc(s)
- Master (outer) case gross weight: 3.76 kg
- Master (outer) case length: 556 mm
- Master (outer) case width: 247 mm
- Master (outer) case height: 153 mm
- Master (outer) case net weight: 2.75 kg
- Harmonized System (HS) code: 85299097
Weight & dimensions
- Width: 152.8 mm
- Depth: 437.2 mm
- Height: 44 mm
- Weight: 2.75 kg
- Package width: 247 mm
- Package depth: 556 mm
- Package height: 153 mm
- Package weight: 3.76 kg
Packaging content
- Cables included: AC
- Mounting brackets included: Yes
