Name: Allied Telesis AT-x530L-28GPX-50 Managed L3+ Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Grey
Brand: ALLIED TELESIS
Price: 3240.26 USD
Availability: InStock

Allied Telesis AT-x530L-28GPX-50 Managed L3+ Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Grey

$3,240.26

$3,240.26 without VAT

Amount

Brand: ALLIED TELESIS

SKU: 86432 PRC: 304101 EAN: 767035217109 PN: 990-006519-50

Description

Specifications

Management features

Switch type: Managed
Switch layer: L3+
Quality of Service (QoS) support: Yes
Traffic classification: Yes
ARP inspection: Yes
Configuring Location Settings (CLI): Yes
System event log: Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 24
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
SFP+ module slots quantity: 4

Network

Networking standards: IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802
10G support: Yes
Port mirroring: Yes
Full duplex: Yes
Policy-based routing: Yes
Flow control support: Yes
Link aggregation: Yes
Spanning tree protocol: Yes
Ethernet LAN data rates: 10,100,1000 Mbit/s
Auto-negotiation: Yes
VLAN support: Yes
Virtual LAN features: Port-based VLAN, Protocol-based VLAN, Tagged VLAN
Number of VLANs: 4094

Data transmission

Switching capacity: 128 Gbit/s
Forwarding rate: 95.2 Mpps
MAC address table: 16000 entries
Latency (1 Gbps): 3.98 µs
Latency (10 Gbps): 1.63 µs
Number of queues: 8
Static route: Yes
Jumbo frames support: Yes
Packet buffer memory: 3 MB

Security

DHCP features: DHCP snooping, DHCPv6 client, DHCPv6 relay
Access Control List (ACL): Yes
IGMP snooping: Yes
Security algorithms: 3DES, AES, DES, MD5, SHA-1, SHA-2, SHA-256, SNMP, SNMPv2, SNMPv3, SSH, SSH-2
MAC address filtering: Yes
SSH/SSL support: Yes
Loop protection: Yes
BPDU filtering/protection: Yes
Authentication: Guest VLAN, MAC-based authentication, Port-based authentication, Web-based authentication
Password protection: Yes
Authentication type: IEEE 802.1x, Network Access Control (NAC), RADIUS
Queue scheduling algorithms: Weighted Round Robin (WRR)

Multicast features

Multicast support: Yes
Multicast features: Multicast forwarding
Multicast Listener Discovery (MLD) snooping: MLDv1, MLDv2

Protocols

Routing protocols: RIP, RIP-2, RIPng
IPv4 & IPv6 features: Dual stack IPv4/IPv6, IPv4/IPv6 access-control list (ACL), IPv6 Telnet

Design

Rack mounting: Yes
Stackable: Yes
Form factor: 1U
Product colour: Grey
LED indicators: Yes
Electromagnetic compatibility: EN55032 class A, FCC class A, VCCI class A, ICES-003 class A, EN55024, EN61000-3-levels 2

Performance

Memory type: DDR3-SDRAM
Internal memory: 1000 MB
Flash memory: 256 MB
Noise level: 42 dB
Export Control Classification Number (ECCN): 5A992C

Power

Power supply included: Yes
Number of power supply units: 2
AC input voltage: 90 - 264 V
AC input frequency: 50 - 60 Hz
Power consumption (max): 890 W

Power over Ethernet (PoE)

Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) type supported: Active PoE
Power over Ethernet plus (PoE+) ports quantity: 24
Power over Ethernet (PoE) power per port: 30 W
Total Power over Ethernet (PoE) budget: 740 W

Operational conditions

Operating temperature (T-T): 0 - 50 °C
Storage temperature (T-T): -25 - 70 °C
Operating relative humidity (H-H): 5 - 90%
Storage relative humidity (H-H): 5 - 95%
Operating altitude: 0 - 3048 m
Heat dissipation: 3037 BTU/h

Weight & dimensions

Width: 441 mm
Depth: 421 mm
Height: 44 mm
Weight: 6.2 kg

Packaging content

Cables included: AC

Packaging data

Package width: 577 mm
Package depth: 548 mm
Package height: 153 mm
Package weight: 8.4 kg

Certificates

Certification: UL, cUL, RoHS

Logistics data

Harmonized System (HS) code: 85176990
