Management features


  • Switch type: Managed
  • Switch layer: L2
  • Quality of Service (QoS) support: Yes
  • MIB support: RFC 1213 MIB II RFC 2819 RMON (group 1, 2, 3, 9) RFC 1215 generic traps RFC 1493 bridge Zyxel private common MIB

Ports & interfaces


  • Basic switching RJ-45 Ethernet ports quantity: 24
  • Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
  • Power connector: AC-in jack

Network


  • Networking standards: IEEE 802.1D, IEEE 802.1ab, IEEE 802.1af, IEEE 802.1s, IEEE 802.1w, IEEE 802.3at, IEEE 802.3az, IEEE 802.3p, IEEE 802.3u, IEEE 80
  • 10G support: No
  • Cable types supported: Cat5, Cat5e
  • Port mirroring: Yes
  • Full duplex: Yes
  • Flow control support: Yes
  • Link aggregation: Yes
  • Auto MDI/MDI-X: Yes
  • Spanning tree protocol: No
  • Ethernet LAN data rates: 10,100,1000 Mbit/s
  • MAC address auto-learning supported: Yes
  • VLAN support: Yes
  • Virtual LAN features: Tagged VLAN, VLAN Identifier ( VLAN ID), Voice VLAN

Data transmission


  • Switching capacity: 48 Gbit/s
  • Forwarding rate: 35.7 Mpps
  • MAC address table: 8000 entries
  • Store-and-forward: Yes
  • Jumbo frames support: Yes
  • Jumbo frames: 9000
  • Packet buffer memory: 0.525 MB

Security


  • DHCP features: DHCP client
  • IGMP snooping: Yes
  • Security algorithms: 802.1x RADIUS
  • MAC address filtering: Yes
  • Static port security: Yes
  • SSH/SSL support: Yes
  • Password protection: Yes
  • Authentication type: HWTACACS+, IEEE 802.1x, RADIUS

Multicast features


  • Multicast support: Yes

Design


  • Rack mounting: Yes
  • Stackable: Yes
  • Product colour: Black
  • Reset button: Yes

Performance


  • Noise level: 26 dB

Power


  • Power supply included: Yes
  • AC input voltage: 100 - 240 V
  • AC input frequency: 50 - 60 Hz
  • Power consumption (typical): 206.5 W

Power over Ethernet (PoE)


  • Power over Ethernet (PoE): Yes

Weight & dimensions


  • Width: 330 mm
  • Depth: 330 mm
  • Height: 44 mm
  • Weight: 2.48 kg

Packaging content


  • Cables included: AC
  • Quick start guide: Yes
  • User guide: Yes
  • Manual: Yes

Packaging data


  • Package type: Box

Logistics data


  • Harmonized System (HS) code: 85176990
