Ubiquiti UniFi Switch Pro Aggregation Managed L3 Grey
More info
Brand: UBIQUITI NETWORKS
836,00 €Stock available: 0 units.
Unavailable
SKU:
118333
PRC:
325217
EAN:
810010072603
PN:
usw-pro-aggregation
Description
The UniFi managed L3 switch comes in grey with 28 SFP+ slots and 4 SFP28 ports, offering a switching capacity of 760 Gbit/s and a throughput of 380 Mpps. This model supports forwarding of 565.44 Mpps, full VLAN support, port mirroring and link aggregation, as well as DHCP server functions for advanced network management. It includes four fans and DC input sockets for power, with LED indicators that facilitate monitoring of the device's status. Designed for environments requiring high fibre connectivity density, this switch aggregates traffic at 10G speeds, ideal for data centres or demanding enterprise networks.
Specifications
Management features
- Switch type: Managed
- Switch layer: L3
Ports & interfaces
- Basic switching RJ-45 Ethernet ports type: No
- SFP+ module slots quantity: 28
- SFP28 ports quantity: 4
- Power connector: DC-in jack
Network
- 10G support: Yes
- Port mirroring: Yes
- Link aggregation: Yes
- VLAN support: Yes
Data transmission
- Switching capacity: 760 Gbit/s
- Throughput: 380 Mpps
- Forwarding rate: 565.44 Mpps
- Static route: Yes
Security
- DHCP features: DHCP server
Design
- Product colour: Grey
- Housing material: Steel
- LED indicators: Yes
- Number of fans: 4 fan(s)
Power
- Power supply included: Yes
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
- DC input voltage: 11.5 V
- Input current: 2 A
- Power consumption (max): 100 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): No
Operational conditions
- Operating temperature (T-T): -5 - 40 °C
- Operating relative humidity (H-H): 10 - 90%
Weight & dimensions
- Width: 442 mm
- Depth: 325 mm
- Height: 44 mm
- Weight: 4.6 kg
Logistics data
- Harmonized System (HS) code: 85176990
