Description
The Trendnet TPE-BG102G switch, in its black finish and 1U form factor, is presented as an unmanaged solution for networks requiring PoE power. With 8 Gigabit Ethernet RJ-45 ports (10/100/1000) and 2 SFP slots, this device supports IEEE 802.3af, 802.3at and 802.3bt standards to supply power to compatible devices. Its switching capacity reaches 20 Gbit/s and its MAC address table manages 8000 entries, along with support for jumbo frames of 9000 bytes and a forwarding rate of 14.88 Mpps. It includes LED indicators, rack mounting and both full duplex and half duplex transmission, with a mean time between failures of 427,588 hours, complying with IEEE 802.1p, 802.3, 802.3x and other listed standards.
Specifications
Management features
- Switch type: Unmanaged
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 8
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- SFP module slots quantity: 2
Network
- Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x
- 10G support: No
- Full duplex: Yes
- Half duplex: Yes
Data transmission
- Switching capacity: 20 Gbit/s
- Forwarding rate: 14.88 Mpps
- MAC address table: 8000 entries
- Jumbo frames support: Yes
- Jumbo frames: 9000
Design
- Rack mounting: Yes
- Form factor: 1U
- Product colour: Black
- LED indicators: Yes
Performance
- Mean time between failures (MTBF): 427588 h
Power
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
Power over Ethernet (PoE)
- Power over Ethernet (PoE): Yes
- Power over Ethernet plus (PoE+) ports quantity: 4
- Power over Ethernet (PoE) power per port: 95 W
- Total Power over Ethernet (PoE) budget: 240 W
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Operating relative humidity (H-H): 0 - 90%
Weight & dimensions
- Width: 330 mm
- Depth: 230 mm
- Height: 44 mm
- Weight: 1.7 kg
Packaging content
- Cables included: AC
- Quick start guide: Yes
- Rack mount kit: Yes
Certificates
- Certification: CE, FCC, ETL
Logistics data
- Harmonized System (HS) code: 85176990
