Name: TP-Link Omada 52-Port Gigabit Smart Switch with 32-Port PoE+
Brand: TP-LINK
Price: 525.6 USD
Availability: InStock

TP-Link Omada 52-Port Gigabit Smart Switch with 32-Port PoE+

$525.60

$525.60 without VAT

Amount

Brand: TP-LINK

SKU: 107916 PRC: 545153 EAN: 8885020620818 PN: SG2452LP

Description

TP-Link Omada 52-Port Gigabit Smart Switch with 32-Port PoE+, Managed, L2/L2+, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting, 1U

Specifications

Management features

Switch type: Managed
Switch layer: L2/L2+
Quality of Service (QoS) support: Yes
Web-based management: Yes
Cloud-managed: Yes
ARP inspection: Yes
Configuring Location Settings (CLI): Yes
System event log: Yes
MIB support: Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 48
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
SFP module slots quantity: 4
Power connector: AC-in jack

Network

Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ab, IEEE 802.3x
10G support: No
Port mirroring: Yes
IP routing: Yes
Flow control support: Yes
Link aggregation: Yes
Auto MDI/MDI-X: Yes
Ethernet LAN data rates: 10,100,1000 Mbit/s
Active link detection: Yes
VLAN support: Yes

Data transmission

Switching capacity: 104 Gbit/s
Forwarding rate: 77.37 Mpps
MAC address table: 16000 entries
Static route: Yes
Jumbo frames support: Yes
Jumbo frames: 9000

Security

DHCP features: DHCP relay, DHCP server
IGMP snooping: Yes
Security algorithms: SNMP, SNMPv2, SNMPv3
MAC address filtering: Yes
SSH/SSL support: Yes
Loop protection: Yes
Authentication type: RADIUS

Design

Rack mounting: Yes
Form factor: 1U
Product colour: Black
LED indicators: Yes

Power

Power source: AC
Power supply included: Yes
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Power consumption (max): 304.5 W

Power over Ethernet (PoE)

Power over Ethernet (PoE): Yes
Power over Ethernet plus (PoE+) ports quantity: 32
Power over Ethernet (PoE) power per port: 30 W
Total Power over Ethernet (PoE) budget: 230 W

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 90%
Heat dissipation: 1035.4 BTU/h

Weight & dimensions

Width: 440 mm
Depth: 330 mm
Height: 44 mm
