Description
The TP-Link LiteWave LS105GP switch is an unmanaged model with five Gigabit Ethernet ports (10/100/1000) in black, designed to expand your network directly and without configuration. It incorporates Power over Ethernet (PoE) according to IEEE 802.3af and 802.3at standards, allowing power to be supplied to compatible devices via the network cable itself. Its MAC address table reaches 2000 entries and offers a switching capacity of 10 Gbit/s, with a forwarding rate of 7.44 Mpps and support for jumbo frames up to 16000 bytes. Management is simplified to the maximum by lacking any managed functions, while Quality of Service (QoS) is present to prioritise traffic in your installation.
Specifications
Management features
- Switch type: Unmanaged
- Quality of Service (QoS) support: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 5
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Network
- Networking standards: IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
- 10G support: No
- Cable types supported: Cat3, Cat5e, Cat4, Cat5
- Flow control support: Yes
- Auto MDI/MDI-X: Yes
- Auto-negotiation: Yes
- MAC address auto-learning supported: Yes
- MAC address auto-aging supported: Yes
Data transmission
- Switching capacity: 10 Gbit/s
- Forwarding rate: 7.44 Mpps
- MAC address table: 2000 entries
- Store-and-forward: Yes
- Jumbo frames: 16000
Security
- IGMP snooping: Yes
Design
- Product colour: Black
- LED indicators: Yes
Power
- Power source: DC/PoE
- Power supply included: Yes
- AC input voltage: 220 V
- AC input frequency: 50 Hz
- DC input voltage: 53.5 V
- Power consumption (max): 74.46 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): Yes
- Power over Ethernet (PoE) ports quantity: 4
- Power over Ethernet (PoE) power per port: 30 W
- Total Power over Ethernet (PoE) budget: 65 W
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 10 - 90%
- Storage relative humidity (H-H): 5 - 90%
- Heat dissipation: 253.16 BTU/h
Weight & dimensions
- Width: 99.8 mm
- Depth: 98 mm
- Height: 25 mm
Packaging content
- User guide: Yes
Packaging data
- Package type: Box
Certificates
- Certification: CE, FCC, RoHS
