Description

Tenda TEG1016G network switch in blue, an unmanaged model with 1U form factor offering 16 Gigabit Ethernet 10/100/1000 ports to easily expand your network. This unmanaged device supports IEEE 802.3, 802.3ab, 802.3u and 802.3x standards, with flow control, auto MDI/MDI-X and full duplex operation for efficient transmission. Its MAC address table reaches 8000 entries and the maximum transfer rate is 1 Gbit/s, ideal for connecting multiple devices. It includes LED indicators for link and power, and supports rack mounting, with MAC address filtering for basic access control.

Specifications

Management features


  • Switch type: Unmanaged

Ports & interfaces


  • Gigabit Ethernet (copper) ports quantity: 16
  • Basic switching RJ-45 Ethernet ports quantity: 16
  • Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)

Network


  • Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
  • 10G support: No
  • Copper ethernet cabling technology: 1000BASE-T, 100BASE-TX, 10BASE-T
  • Full duplex: Yes
  • Flow control support: Yes
  • Auto MDI/MDI-X: Yes

Data transmission


  • Supported data transfer rates: 10/100/1000 Mbps
  • MAC address table: 8000 entries
  • Maximum data transfer rate: 1 Gbit/s

Security


  • MAC address filtering: Yes

Design


  • Rack mounting: Yes
  • Form factor: 1U
  • Product colour: Blue
  • LED indicators: Link, Power

Power


  • AC input voltage: 100 - 240 V
  • AC input frequency: 50 - 60 Hz
  • Output power: 20 W

Power over Ethernet (PoE)


  • Power over Ethernet (PoE): No

Other features


  • Dimensions (WxDxH): 208 x 440 x 44 mm
  • Connectivity technology: Wired
  • Bandwidth: 32 Gbit/s
  • Networking features: Ethernet, Fast Ethernet, Gigabit Ethernet
  • Wi-Fi: No
  • Power LED: Yes
  • Size (imperial): 48.3 cm (19")

Operational conditions


  • Operating temperature (T-T): 0 - 40 °C
  • Storage temperature (T-T): -40 - 70 °C
  • Operating relative humidity (H-H): 10 - 90%
  • Storage relative humidity (H-H): 5 - 95%

Weight & dimensions


  • Width: 208 mm
  • Depth: 440 mm
  • Height: 44 mm

Packaging content


  • User guide: Yes

Certificates


  • Certification: CE, RoHS

Logistics data


  • Harmonized System (HS) code: 85176990
