Synology DiskStation DS423+ NAS/storage server Rack (8U) Intel® Celeron® J4125 2 GB DDR4 0 TB DiskStation Manager Black

Not avaliable

More info

Brand: SYNOLOGY
SKU: 116254 PRC: 426992 EAN: 4711174725007 PN: DS423+

Description

Specifications

Storage

  • Supported storage drive interfaces: Serial ATA
  • Storage drive sizes supported: 2.5, 3.5"
  • Number of M.2 (M & B) slots: 2
  • RAID support: Yes
  • RAID levels: 0, 1, 5, 6, 10, JBOD
  • Hot-swap drive bays: Yes
  • Supported file systems: BTRFS, FAT32, HFS+, NTFS, exFAT, ext3, ext4
  • Storage drives installed: No
  • Total installed storage capacity: 0 TB
  • Number of storage drives supported: 4
  • Installed storage drive type: No
  • Supported storage drive types: HDD & SSD

Processor

  • Processor manufacturer: Intel
  • Processor family: Intel® Celeron®
  • Processor model: J4125
  • Processor frequency: 2 GHz
  • Processor boost frequency: 2.7 GHz
  • Processor cores: 4
  • Processor threads: 4
  • Processor cache: 4 MB
  • CPU configuration (max): 1
  • Number of processors supported: 1

Memory

  • Internal memory: 2 GB
  • Internal memory type: DDR4
  • Maximum RAM supported: 6 GB
  • Memory form factor: SO-DIMM

Network

  • Ethernet LAN: Yes
  • Ethernet LAN data rates: 10, 100, 1000 Mbit/s
  • Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
  • iSCSI support: Yes
  • Supported network protocols: SMB, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP / VPN (PPTP, OpenVPN™, L2TP)

Ports & interfaces

  • USB port: Yes
  • USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
  • Ethernet LAN (RJ-45) ports: 2

Design

  • Chassis type: Rack (8U)
  • Cooling type: Active
  • Product colour: Black
  • Number of fans: 2 fan(s)
  • Fan diameter: 9.2 cm
  • LED indicators: Yes
  • Built-in display: No
  • Cable lock slot: Yes
  • Cable lock slot type: Kensington
  • Built-in speaker(s): No

Performance

  • Type: NAS
  • Device class: Home & Home Office
  • Backup function: Yes
  • Backup features: Cloud, iSCSI LUN
  • Buzzer: Yes
  • Multilingual support: Yes
  • Card reader integrated: No
  • Security algorithms: HTTPS, SSH, SSL/TLS
  • Access Control List (ACL): Yes
  • Reset button: Yes
  • On/off switch: Yes
  • Built-in FTP server: Yes
  • Browser supported: Google Chrome®, Firefox®, Microsoft Edge®, Safari 13+
  • System log: Yes

Software

  • Operating system installed: DiskStation Manager

Power

  • Power supply location: External
  • Number of power supply units: 1
  • Redundant power supply (RPS) support: No
  • AC input voltage: 100 - 240 V
  • AC input frequency: 50 / 60 Hz

Weight & dimensions

  • Width: 199 mm
  • Depth: 223 mm
  • Height: 166 mm
  • Weight: 2.18 kg

Packaging content

  • External power adapter: Yes
  • Cables included: AC, LAN (RJ-45)
  • Power cables quantity: 1

Processor special features

  • Embedded options available: No
  • Enhanced Intel SpeedStep Technology: Yes
  • Execute Disable Bit: Yes
  • Idle States: Yes
  • Intel 64: Yes
  • Intel Virtualization Technology (VT-x): Yes
  • Intel Virtualization Technology for Directed I/O (VT-d): Yes
  • Intel VT-x with Extended Page Tables (EPT): Yes

Operational conditions

  • Operating temperature (T-T): 0 - 40 °C
  • Operating relative humidity (H-H): 8 - 80%
  • Storage temperature (T-T): -20 - 60 °C
  • Storage relative humidity (H-H): 5 - 95%
  • Operating altitude: 0 - 5000 m
