Description
Synology DiskStation DS423+ is a 4-bay NAS server in 8U rack format, equipped with an Intel Celeron J4125 processor at 2 GHz (turbo up to 2.7 GHz) and 2 GB of DDR4 memory. This model arrives with no storage drives installed, so you can configure it with up to four 2.5" or 3.5" SATA drives, both HDD and SSD, and it features two additional M.2 slots for cache or storage. It supports RAID levels 0, 1, 5, 6, 10 and JBOD, with file systems such as BTRFS, ext4 or NTFS, and its hot-swap bays allow you to remove or insert drives without interrupting service. With DiskStation Manager as the operating system, you manage backups, shared files and network applications centrally from a single panel.
Specifications
Storage
- Supported storage drive interfaces: Serial ATA
- Storage drive sizes supported: 2.5, 3.5"
- Number of M.2 (M & B) slots: 2
- RAID support: Yes
- RAID levels: 0, 1, 5, 6, 10, JBOD
- Hot-swap drive bays: Yes
- Supported file systems: BTRFS, FAT32, HFS+, NTFS, exFAT, ext3, ext4
- Storage drives installed: No
- Total installed storage capacity: 0 TB
- Number of storage drives supported: 4
- Installed storage drive type: No
- Supported storage drive types: HDD & SSD
Processor
- Processor manufacturer: Intel
- Processor family: Intel® Celeron®
- Processor model: J4125
- Processor frequency: 2 GHz
- Processor boost frequency: 2.7 GHz
- Processor cores: 4
- Processor threads: 4
- Processor cache: 4 MB
- CPU configuration (max): 1
- Number of processors supported: 1
Memory
- Internal memory: 2 GB
- Internal memory type: DDR4
- Maximum RAM supported: 6 GB
- Memory form factor: SO-DIMM
Network
- Ethernet LAN: Yes
- Ethernet LAN data rates: 10, 100, 1000 Mbit/s
- Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
- iSCSI support: Yes
- Supported network protocols: SMB, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP / VPN (PPTP, OpenVPN™, L2TP)
Ports & interfaces
- USB port: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
- Ethernet LAN (RJ-45) ports: 2
Design
- Chassis type: Rack (8U)
- Cooling type: Active
- Product colour: Black
- Number of fans: 2 fan(s)
- Fan diameter: 9.2 cm
- LED indicators: Yes
- Built-in display: No
- Cable lock slot: Yes
- Cable lock slot type: Kensington
- Built-in speaker(s): No
Performance
- Type: NAS
- Device class: Home & Home Office
- Backup function: Yes
- Backup features: Cloud, iSCSI LUN
- Buzzer: Yes
- Multilingual support: Yes
- Card reader integrated: No
- Security algorithms: HTTPS, SSH, SSL/TLS
- Access Control List (ACL): Yes
- Reset button: Yes
- On/off switch: Yes
- Built-in FTP server: Yes
- Browser supported: Google Chrome®, Firefox®, Microsoft Edge®, Safari 13+
- System log: Yes
Software
- Operating system installed: DiskStation Manager
Power
- Power supply location: External
- Number of power supply units: 1
- Redundant power supply (RPS) support: No
- AC input voltage: 100 - 240 V
- AC input frequency: 50 / 60 Hz
Weight & dimensions
- Width: 199 mm
- Depth: 223 mm
- Height: 166 mm
- Weight: 2.18 kg
Packaging content
- External power adapter: Yes
- Cables included: AC, LAN (RJ-45)
- Power cables quantity: 1
Processor special features
- Embedded options available: No
- Enhanced Intel SpeedStep Technology: Yes
- Execute Disable Bit: Yes
- Idle States: Yes
- Intel 64: Yes
- Intel Virtualization Technology (VT-x): Yes
- Intel Virtualization Technology for Directed I/O (VT-d): Yes
- Intel VT-x with Extended Page Tables (EPT): Yes
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Operating relative humidity (H-H): 8 - 80%
- Storage temperature (T-T): -20 - 60 °C
- Storage relative humidity (H-H): 5 - 95%
- Operating altitude: 0 - 5000 m
