Description
NAS storage server in tower format with a four-core AMD Ryzen Embedded V1500B processor at 2.2 GHz and 4 GB of DDR4 memory, ready to accommodate up to 12 2.5 or 3.5-inch SATA drives, including HDDs and SSDs. This Synology DiskStation DS2422+ supports a maximum capacity of 108 TB and supports file systems such as BTRFS, ext4, NTFS or FAT, with hot-swap bays for replacing drives without powering down the unit. RAID levels 0, 5, 6, 10 and JBOD allow you to configure redundancy or performance as needed, while its compatibility with 3.5-inch drives makes it easy to expand storage space progressively.
Specifications
Storage
- Storage drive capacity: 0 GB
- Supported storage drive interfaces: Serial ATA, Serial ATA II, Serial ATA III
- Storage drive sizes supported: 2.5, 3.5"
- Maximum supported storage capacity: 108 TB
- RAID support: Yes
- RAID levels: 0, 5, 6, 10, JBOD
- Hot-swap drive bays: Yes
- Supported file systems: BTRFS, Fat, HFS+, NTFS, ext3, ext4
- Storage drives installed: No
- Total installed storage capacity: 0 TB
- Number of storage drives supported: 12
- Installed storage drive type: No
- Supported storage drive types: HDD & SSD
Processor
- Processor manufacturer: AMD
- Processor generation: AMD Ryzen Embedded V1000 Series
- Processor family: Ryzen Embedded
- Processor model: V1500B
- Processor frequency: 2.2 GHz
- Processor cores: 4
- Number of processors supported: 1
Memory
- Internal memory: 4 GB
- Internal memory type: DDR4
- Maximum RAM supported: 32 GB
- Memory slots: 2
- Memory form factor: SO-DIMM
- ECC: Yes
Network
- Ethernet LAN: Yes
- Ethernet LAN data rates: 1000 Mbit/s
- Wake-on-LAN ready: Yes
- Supported network protocols: SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV
- Link aggregation: Yes
Ports & interfaces
- USB port: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
- Ethernet LAN (RJ-45) ports: 4
- PCI Express x8 (Gen 3.x) slots: 1
Design
- Chassis type: Tower
- Cooling type: Active
- Product colour: Black
- Number of fans: 2 fan(s)
- Fan diameter: 12 cm
- Fan diameter 2: 12 cm
- Drive bay locking: Yes
Performance
- Type: NAS
- Device class: Small & Medium Business
- Backup function: Yes
- Backup features: Cloud, iSCSI LUN
- Multilingual support: Yes
- Noise level: 25 dB
- Web-based management: Yes
- Access Control List (ACL): Yes
- Browser supported: Chrome, Firefox, Edge, Internet Explorer, Safari
Software
- Operating system installed: DiskStation Manager
Power
- Power supply location: Built-in
- Power supply unit (PSU) capacity: 550 W
- Number of power supply units: 1
- Power consumption (typical): 73.11 W
- Power consumption (HDD standby): 32.12 W
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
Weight & dimensions
- Width: 300 mm
- Depth: 340 mm
- Height: 270 mm
- Weight: 9.5 kg
Packaging content
- Cables included: AC, LAN (RJ-45)
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Operating relative humidity (H-H): 5 - 95%
- Storage temperature (T-T): -20 - 60 °C
- Storage relative humidity (H-H): 5 - 95%
Logistics data
- Harmonized System (HS) code: 84714100
Other features
- Compliance certificates: RoHS
- Certification: FCC CE BSMI VCCI RCM UKCA EAC CCC KC UL
