Description
The Synology DiskStation DS224+ is a black desktop NAS storage server that arrives with no drives installed, allowing you to mount up to two 2.5" or 3.5" SATA drives, both HDD and SSD, with total capacity depending on you as you start from scratch. Its quad-core Intel Celeron J4125 processor runs at 2 GHz with a 2.7 GHz turbo boost, accompanied by 2 GB of DDR4 memory, sufficient for managing files on systems such as BTRFS, ext4, NTFS or exFAT. It includes RAID support with levels 0, 1 and JBOD, as well as compatibility with RAID configurations since the option is enabled by default, ideal for organising your data with redundancy or grouped as you prefer.
Specifications
Storage
- Storage drive capacity: 0 GB
- Storage drive interface: Serial ATA
- Storage drive size: 2.5/3.5"
- RAID support: Yes
- RAID levels: 0, 1, JBOD
- Supported file systems: BTRFS, Fat, HFS+, NTFS, exFAT, ext3, ext4
- Storage drives installed: No
- Total installed storage capacity: 0 TB
- Number of storage drives supported: 2
- Installed storage drive type: No
- Supported storage drive types: HDD & SSD
Processor
- Processor manufacturer: Intel
- Processor family: Intel® Celeron®
- Processor model: J4125
- Processor frequency: 2 GHz
- Processor boost frequency: 2.7 GHz
- Processor cores: 4
- CPU configuration (max): 1
Memory
- Internal memory: 2 GB
- Internal memory type: DDR4
- Maximum RAM supported: 6 GB
Network
- Ethernet LAN: Yes
- iSCSI support: Yes
- Wake-on-LAN ready: Yes
- Supported network protocols: SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV
Ports & interfaces
- USB port: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
- Ethernet LAN (RJ-45) ports: 2
Design
- Chassis type: Desktop
- Cooling type: Active
- Product colour: Black
- Number of fans: 1 fan(s)
- Fan diameter: 9.2 cm
- LED indicators: Yes
Performance
- Type: NAS
- Device class: Home & Home Office
- Backup function: Yes
- Number of users: 1200 user(s)
- Noise level: 22 dB
- Access Control List (ACL): Yes
- On/off switch: Yes
- Browser supported: Google Chrome, Firefox, Microsoft Edge, Safari
- USB copy function: Yes
Power
- Power supply unit (PSU) capacity: 60 W
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
Weight & dimensions
- Width: 108 mm
- Depth: 232.2 mm
- Height: 165 mm
- Weight: 1.3 kg
Packaging content
- External power adapter: Yes
- Cables included: AC, LAN (RJ-45)
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Operating relative humidity (H-H): 5 - 95%
- Storage temperature (T-T): -20 - 60 °C
