StarTech.com HDMI over IP Extender Kit with Video Wall Support - 1080p

556.00 €

459.50 € without VAT

Amount

Brand: STARTECH.COM

SKU: 115864 PRC: 252147 EAN: 65030878456 PN: ST12MHDLAN2K

Description

StarTech.com HDMI over IP Extender Kit with Video Wall Support - 1080p - HDMI over CAT5e / CAT6 Transmitter and Receiver Kit (ST12MHDLAN2K)

Specifications

Features

Type: AV transmitter & receiver
Maximum resolution: 1920 x 1080 pixels
Cable types supported: Cat5e, Cat6
Maximum transfer distance: 100 m
Maximum refresh rate: 60 Hz
Audio output channels: 7.1 channels
LED indicators: Link, Network, Power, Status
Supported video modes: 720p, 1080p
Supported graphics resolutions: 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1280 x 800, 1360 x 768 (WXGA), 1440 x 900, 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080
Rack mounting: Yes
Daisy chain: Yes
Rubber feet: Yes
Product colour: Black

Ports & interfaces

RJ-45 input ports: 1
RJ-45 output ports: 1
HDMI in: 1
Number of HDMI outputs: 1
Audio input: 2 x 3.5 mm
Audio output: 2 x 3.5 mm
RJ-11 ports quantity: 4
3.5 mm (1/8-inch) in: Yes
3.5 mm (1/8-inch) out: Yes

Power

AC input voltage: 100 - 240 V
Operating voltage: 12 V
Input current: 0.6 A
Output current: 1.5 A
Power consumption (typical): 10 W
External power adapter: Yes
Power plug type: Type M

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -10 - 60 °C
Operating relative humidity (H-H): 0 - 80%

Weight & dimensions

Width: 118 mm
Depth: 131 mm
Height: 31 mm
Weight: 1.2 kg

Packaging data

Package width: 235 mm
Package depth: 365 mm
Package height: 75 mm
Package weight: 2.3 kg

Packaging content

AC adapter included: Yes
Cables included: LAN (RJ-45), Phone (RJ-11)
Included power plug types: ANZ, EU, JP, NA, UK, US
Manual: Yes
IR blaster included: Yes
IR receiver included: Yes
Mounting kit: Yes

Technical details

Sustainability compliance: Yes
Compliance certificates: CE, RoHS

Logistics data

Master (outer) case width: 385 mm
Master (outer) case length: 390 mm
Master (outer) case height: 270 mm
Products per master (outer) case: 6 pc(s)
