Name: Phasak UPS Sirius Interative 1260 VA - PH 7312
Brand: PHASAK
Availability: OutOfStock

Phasak UPS Sirius Interative 1260 VA - PH 7312

Not avaliable

Amount

Brand: PHASAK

SKU: 87867 PRC: 317848 EAN: 5605922007240 PN: ph 7312

Description

Specifications

Features

Auto-restart: Yes
Auto shut-off: Yes
Power source type: AC/DC
Detachable power cord: Yes
UPS topology: Line-Interactive
Output power capacity: 1.26 kVA
Output power: 720 W
Waveform: Pseudo sine
Input operation voltage (min): 162 V
Input operation voltage (max): 290 V
Input frequency: 50/60 Hz
Output operation voltage (min): 220 V
Output operation voltage (max): 240 V
Output frequency: 50/60 Hz
Automatic Voltage Regulation (AVR): Yes
Response time: 4 ms
Power factor: 0.6
Input power factor: 1
Output power factor: 0.6
ECO mode: No
Emergency Power Off (EPO): No
Noise level: 45 dB
Surge protection: Yes
Surge protection features: A/V
Power protection features: Battery discharge, Over current, Over power, Over voltage, Overcharge, Overheating, Overload, Short circuit
Carrying handle(s): No
Audible alarm(s): Yes
Audible alarm modes: Fault, Low battery alarm, Overload alarm

Ports & interfaces

AC outlet types: Type F
Power plug: Type F
AC outlets quantity: 4 AC outlet(s)
Number of type F outputs: 4
Number of outlets (Battery backup & protection): 4
Number of outlets (Protection): 1
USB port: Yes
USB 2.0 ports quantity: 1
USB port type: USB Type-B
Serial interface: No
Emergency Power Off (EPO) connector: No
Remote Power Off (RPO)/Remote On-Off (ROO) connector: No
SmartSlot: No
Programmable sockets: No

Battery

Battery technology: Lead-Calcium (Pb-Ca)
Battery capacity: 7 Ah
Battery voltage: 12 V
Number of batteries supported: 2
Typical backup time at full load: 15 min
Typical backup time at half load: 8 min
Battery recharge time: 8 h
Hot-swap battery: No
Automatic battery test: No
Cold start: Yes

Design

Form factor: Compact
Cable length: 1 m
Modular: No
Cooling type: Passive
Built-in fan: Yes
Fan speed control: No
Product colour: Black
Display type: LCD

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 0 - 90%
Storage relative humidity (H-H): 0 - 90%

Certificates

Compliance certificates: CE

Packaging content

Rack mount kit: No
Manual: Yes

Sustainability

Sustainability compliance: Yes

Weight & dimensions

Width: 148 mm
Depth: 298 mm
Height: 178 mm
Weight: 8.7 kg
Battery width: 15.1 cm
Battery depth: 6.5 cm
Battery height: 9.5 cm
Battery weight: 2.2 kg

Packaging data

Screws included: No
Bracket: No
Rubber feet: No
Management card included: Yes
Resource CD: No
Warranty card: Yes
Software CD: No
Manual languages: Spanish, Portuguese
Package width: 330 mm
Package depth: 220 mm
Package height: 220 mm
Package weight: 9 kg
Package type: Box

Logistics data

Serialized: Yes
Quantity per pack: 1 pc(s)

Other features

Power plug type: Type F
