Categories
Peripherals
UPS
Phasak UPS Protekt Torre Interactive 2160 VA - PH 7621

Return

Few units

Product 1 image

Product 2 image

Product 3 image

Product 4 image

Phasak UPS Protekt Torre Interactive 2160 VA - PH 7621

$199.96

$199.96 without VAT

Amount

Brand: PHASAK

SKU: 87160 PRC: 310605 EAN: 5605922009244 PN: ph 7621

Description

Specifications

Features

UPS topology: Line-Interactive
Output power capacity: 2.16 kVA
Output power: 1400 W
Waveform: Pure sine
Input operation voltage (min): 165 V
Input operation voltage (max): 290 V
Input frequency: 50/60 Hz
Output operation voltage (min): 220 V
Output operation voltage (max): 240 V
Output frequency: 50/60 Hz
Automatic Voltage Regulation (AVR): Yes
Transfer time (Line Mode to Battery Mode): 4 ms
Response time: 4 ms
Number of input phases: 1
Number of output phases: 1
Power factor: 0.6
Output power factor: 0.6
ECO mode: No
Emergency Power Off (EPO): Yes
Noise level: 45 dB
Surge protection: Yes
Power protection features: Battery discharge, Over power, Overcharge, Overheating, Overload
Carrying handle(s): No
Audible alarm(s): Yes
Audible alarm modes: Fault, Low battery alarm, Overload alarm
Auto-restart: Yes
Auto shut-off: Yes
Power source type: AC
Detachable power cord: Yes

Ports & interfaces

AC outlet types: Type F
Power plug: Type F
AC outlets quantity: 4 AC outlet(s)
Number of type F outputs: 4
Number of outlets (Battery backup & protection): 4
Number of outlets (Protection): 1
USB port: Yes
USB 2.0 ports quantity: 1
USB port type: USB Type-B
Serial interface: Yes
Serial interface type: RJ-45, RS-232
Serial ports quantity: 1
RS-232 ports: 1
Ethernet LAN (RJ-45) ports: 2
Emergency Power Off (EPO) connector: No
SmartSlot: Yes
Programmable sockets: No

Battery

Battery technology: Lead-Calcium (Pb-Ca)
Battery capacity: 9 Ah
Battery voltage: 12 V
Number of batteries supported: 2
Typical backup time at full load: 15 min
Typical backup time at half load: 8 min
Battery recharge time: 4 h
Battery recharge time (90%): 8 h
Charging current: 1 A
Hot-swap battery: No
Automatic battery test: No
Cold start: Yes
Rechargeable battery: Yes
Battery level indicator: Yes
Off-mode charging: Yes

Design

Form factor: Compact
Cable length: 1 m
Modular: No
Cooling type: Passive
Built-in fan: Yes
Product colour: Grey
Control type: Buttons
Display type: LCD
LED indicators: Activity, Alarm, Battery level, Charging, Power, Power fail, Status

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 0 - 90%

Certificates

Compliance certificates: CE

Packaging content

Batteries included: Yes
Rack mount kit: No
Cables included: Power load cable
Manual: Yes
Quick installation guide: Yes

Sustainability

Sustainability compliance: Yes

Weight & dimensions

Width: 140 mm
Depth: 327 mm
Height: 191 mm
Weight: 13.5 kg
Battery width: 15.1 cm
Battery depth: 6.5 cm
Battery height: 9.5 cm
Battery weight: 2.2 kg

Packaging data

Screws included: No
Bracket: No
Rubber feet: Yes
Management card included: Yes
Fuse included: Yes
Resource CD: No
Warranty card: Yes
Software CD: No
Manual languages: English, Spanish, Portuguese
Package width: 513 mm
Package depth: 288 mm
Package height: 445 mm
Package weight: 15 kg
Package type: Box

Logistics data

Serialized: Yes
Quantity per pack: 1 pc(s)
Warranty period: 3 year(s)

Other features

Power plug type: Type F
