Description
UPS system with online double conversion of 6000 VA, reference PH 9360 from the manufacturer Phasak, designed to provide stable power in professional environments requiring constant protection. It regulates output voltage with 1% precision and offers an output frequency of 50/60 Hz, with a total harmonic distortion of only 2% on both input and output, ensuring clean current. Its 4 ms response time acts quickly against fluctuations, while its emergency shutdown and auto shutdown enable safe system control in critical situations.
Specifications
Features
- Output voltage regulation: 1%
- Automatic Voltage Regulation (AVR): Yes
- Response time: 4 ms
- Number of input phases: 1
- Number of output phases: 1
- Efficiency (On-line mode): 1%
- Power factor: 1
- Input power factor: 1
- Output power factor: 1
- Crest factor: 3:1
- ECO mode: Yes
- Emergency Power Off (EPO): Yes
- Output voltage Total Harmonic Distortion (THD): 2%
- Input current Total Harmonic Distortion (THD): 2%
- Noise level: 55 dB
- Surge protection: No
- Power protection features: Battery discharge, Over power, Over voltage, Overcharge, Overheating, Overload
- Carrying handle(s): No
- Audible alarm(s): Yes
- Audible alarm modes: Battery replacement, Fault, Low battery alarm, Overload alarm
- Potential-free output: No
- Auto-restart: Yes
- Auto shut-off: Yes
- Power source type: AC
- Detachable power cord: Yes
- UPS topology: Double-conversion (Online)
- Output power capacity: 6 kVA
- Output power: 6000 W
- Waveform: Pure sine
- Input operation voltage (min): 110 V
- Input operation voltage (max): 176 V
- Input frequency: 50/60 Hz
- Output operation voltage (min): 208 V
- Output operation voltage (max): 240 V
- Output frequency: 50/60 Hz
- Output frequency regulation: 50/60 Hz
Ports & interfaces
- AC outlet types: Terminal
- Power plug: Terminal
- Number of type F outputs: 3
- USB port: Yes
- USB 2.0 ports quantity: 1
- USB port type: USB Type-B
- Serial interface: Yes
- Serial interface type: RS-232
- Serial ports quantity: 2
- RS-232 ports: 1
- Ethernet LAN (RJ-45) ports: 2
- Emergency Power Off (EPO) connector: Yes
- SmartSlot: Yes
Battery
- Battery technology: Lead-Calcium (Pb-Ca)
- Battery capacity: 7 Ah
- Battery voltage: 12 V
- Number of batteries supported: 20
- Typical backup time at full load: 15 min
- Typical backup time at half load: 8 min
- Battery recharge time: 4 h
- Automatic battery test: No
- Cold start: Yes
Design
- Form factor: Mini Tower
- Cable length: 1 m
- Modular: No
- Cooling type: Active
- Built-in fan: Yes
- Product colour: Beige
- Control type: Buttons
- Display type: LCD
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): 0 - 40 °C
- Operating relative humidity (H-H): 20 - 95%
- Storage relative humidity (H-H): 20 - 95%
Certificates
- Compliance certificates: CE
Packaging content
- Rack mount kit: Yes
- Cables included: Power load cable
- Manual: Yes
Sustainability
- Sustainability compliance: Yes
Weight & dimensions
- Width: 438 mm
- Depth: 580 mm
- Height: 133 mm
- Weight: 17 kg
- Battery width: 15.1 cm
- Battery depth: 6.5 cm
- Battery height: 9.5 cm
- Battery weight: 2.2 kg
Packaging data
- Software CD: No
- Manual languages: English, Spanish, Portuguese
- Package width: 440 mm
- Package depth: 470 mm
- Package height: 250 mm
- Package weight: 15.5 kg
- Package type: Box
Logistics data
- Serialized: No
- Quantity per pack: 1 pc(s)
