Description
Specifications
Management features
- Switch type: Managed
- Switch layer: L2/L3/L4
- Quality of Service (QoS) support: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 24
- Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000)
- SFP+ module slots quantity: 2
- Console port: RJ-45
- USB 2.0 ports quantity: 1
Network
- Networking standards: IEEE 802.1x, IEEE 802.3ad, IEEE 802.3az
- 10G support: Yes
- Copper ethernet cabling technology: 10GBASE-T
- IP routing: Yes
- Auto-sensing: Yes
- VLAN support: Yes
- Virtual LAN features: Private VLAN
- Number of VLANs: 4096
Data transmission
- Switching capacity: 128 Gbit/s
- Forwarding rate: 357 Mpps
- MAC address table: 16000 entries
- Latency (10 Gbps): 2.74 µs
- Number of static routes: 64
- Jumbo frames support: Yes
- Packet buffer memory: 16 MB
Security
- BPDU filtering/protection: Yes
- DHCP features: DHCP server
- Access Control List (ACL): Yes
- IGMP snooping: Yes
- Security algorithms: HTTPS, SNMP, SSH
- SSH/SSL support: Yes
Multicast features
- Multicast support: Yes
- Number of multicast groups filtered: 4000
Design
- Rack mounting: Yes
- Stackable: Yes
- Form factor: 1U
- Product colour: Black
- Number of fans: 1 fan(s)
Performance
- Built-in processor: Yes
- Processor frequency: 800 MHz
- Internal memory: 1024 MB
- Flash memory: 256 MB
- Noise level: 39.8 dB
Power
- Power supply included: Yes
- Redundant power supply (RPS) support: Yes
- Number of power supply units: 1
- AC input voltage: 110 - 240 V
- Power consumption (typical): 577 W
- Power consumption (max): 833.2 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): Yes
- Power over Ethernet plus (PoE+) ports quantity: 24
- Total Power over Ethernet (PoE) budget: 480 W
Operational conditions
- Heat dissipation: 196988 BTU/h
Weight & dimensions
- Weight: 5.09 kg
Logistics data
- Harmonized System (HS) code: 85176990
