NETGEAR M4300-28G-PoE+ Managed L2/L3/L4 10G Ethernet (100/1000/10000) Power over Ethernet (PoE) 1U Black

Name: NETGEAR M4300-28G-PoE+ Managed L2/L3/L4 10G Ethernet (100/1000/10000) Power over Ethernet (PoE) 1U Black
Brand: NETGEAR
Availability: OutOfStock

Not avaliable

NETGEAR M4300-28G-PoE+ Managed L2/L3/L4 10G Ethernet (100/1000/10000) Power over Ethernet (PoE) 1U Black. More info

Amount

Brand: NETGEAR

SKU: 77498 PRC: 137583 EAN: 606449112771 PN: GSM4328PA-100NES

Description

Specifications

Management features

Switch type: Managed
Switch layer: L2/L3/L4
Quality of Service (QoS) support: Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 24
Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000)
SFP+ module slots quantity: 2
Console port: RJ-45
USB 2.0 ports quantity: 1

Network

Networking standards: IEEE 802.1x, IEEE 802.3ad, IEEE 802.3az
10G support: Yes
Copper ethernet cabling technology: 10GBASE-T
IP routing: Yes
Auto-sensing: Yes
VLAN support: Yes
Virtual LAN features: Private VLAN
Number of VLANs: 4096

Data transmission

Switching capacity: 128 Gbit/s
Forwarding rate: 357 Mpps
MAC address table: 16000 entries
Latency (10 Gbps): 2.74 µs
Number of static routes: 64
Jumbo frames support: Yes
Packet buffer memory: 16 MB

Security

BPDU filtering/protection: Yes
DHCP features: DHCP server
Access Control List (ACL): Yes
IGMP snooping: Yes
Security algorithms: HTTPS, SNMP, SSH
SSH/SSL support: Yes

Multicast features

Multicast support: Yes
Number of multicast groups filtered: 4000

Design

Rack mounting: Yes
Stackable: Yes
Form factor: 1U
Product colour: Black
Number of fans: 1 fan(s)

Performance

Built-in processor: Yes
Processor frequency: 800 MHz
Internal memory: 1024 MB
Flash memory: 256 MB
Noise level: 39.8 dB

Power

Power supply included: Yes
Redundant power supply (RPS) support: Yes
Number of power supply units: 1
AC input voltage: 110 - 240 V
Power consumption (typical): 577 W
Power consumption (max): 833.2 W

Power over Ethernet (PoE)

Power over Ethernet (PoE): Yes
Power over Ethernet plus (PoE+) ports quantity: 24
Total Power over Ethernet (PoE) budget: 480 W

Operational conditions

Heat dissipation: 196988 BTU/h

Weight & dimensions

Weight: 5.09 kg

Logistics data

Harmonized System (HS) code: 85176990
