Name: NETGEAR M4300-52G-PoE+ 1000W PSU Managed L2/L3/L4 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Black
Brand: NETGEAR
Availability: OutOfStock

NETGEAR M4300-52G-PoE+ 1000W PSU Managed L2/L3/L4 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Black

Not avaliable

NETGEAR M4300-52G-PoE+ 1000W PSU Managed L2/L3/L4 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Black. More info

Amount

Brand: NETGEAR

SKU: 77358 PRC: 135414 EAN: 606449112863 PN: GSM4352PB-100NES

Description

Specifications

Management features

Switch type: Managed
Switch layer: L2/L3/L4
Quality of Service (QoS) support: Yes
Web-based management: Yes
ARP inspection: Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 48
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
SFP+ module slots quantity: 2
Fiber optic connector: SFP+
Console port: RJ-45/Mini-USB
USB 2.0 ports quantity: 1

Network

Networking standards: IEEE 802.11ad, IEEE 802.11az, IEEE 802.3ad, IEEE 802.3az
10G support: Yes
Cable types supported: Cat5, Cat5e, Cat6, Cat7, Fiber
Port mirroring: Yes
IP routing: Yes
Flow control support: Yes
Link aggregation: Yes
Rate limiting: Yes
Auto MDI/MDI-X: Yes
Spanning tree protocol: Yes
Auto-sensing: Yes
Auto-negotiation: Yes
VLAN support: Yes
Virtual LAN features: Private VLAN
Number of VLANs: 4000

Optical fiber

Fiber ethernet cabling technology: 10GBASE-LR, 10GBASE-LRM, 10GBASE-SR

Data transmission

Switching capacity: 176 Gbit/s
Forwarding rate: 357 Mpps
MAC address table: 16000 entries
Store-and-forward: Yes
Number of static routes: 64
Jumbo frames support: Yes
Jumbo frames: 9000
Packet buffer memory: 16 MB

Security

DHCP features: DHCP server, DHCP client
Access Control List (ACL): Yes
IGMP snooping: Yes
Security algorithms: HTTPS, SNMP, SSH
SSH/SSL support: Yes
BPDU filtering/protection: Yes

Multicast features

Multicast support: Yes
Number of multicast groups filtered: 4000

Design

Rack mounting: Yes
Stackable: Yes
Form factor: 1U
Product colour: Black
LED indicators: Activity, Power, Speed
Safety: CSA 22.2 #950, UL 1950)/cUL IEC 950/EN 60950
Electromagnetic compatibility: CE, FCC 15 A, VCCI A, A EN 55022, (CISPR 22) A, EN 50082-1, EN 55024

Performance

Built-in processor: Yes
Processor frequency: 800 MHz
Internal memory: 1024 MB
Flash memory: 256 MB
Noise level: 39.8 dB
Mean time between failures (MTBF): 673207 h

Power

Power supply included: Yes
Redundant power supply (RPS) support: Yes
Number of power supply units: 1
AC input voltage: 120 - 230 V
Power consumption (max): 888 W

Power over Ethernet (PoE)

Power over Ethernet (PoE): Yes
Power over Ethernet plus (PoE+) ports quantity: 48
Power over Ethernet (PoE) power per port: 30 W
Total Power over Ethernet (PoE) budget: 591 W

Operational conditions

Operating temperature (T-T): 0 - 50 °C
Storage temperature (T-T): -20 - 70 °C
Operating relative humidity (H-H): 0 - 90%
Storage relative humidity (H-H): 0 - 95%
Operating altitude: 0 - 3000 m
Non-operating altitude: 0 - 3000 m
Heat dissipation: 303163 BTU/h

Weight & dimensions

Width: 440 mm
Depth: 388 mm
Height: 44 mm
Weight: 6.67 kg

Packaging content

Cables included: AC, LAN (RJ-45), Mini-USB
User guide: Yes
Rack mount kit: Yes

Packaging data

Rubber feet: Yes
Resource CD: Yes

Logistics data

Harmonized System (HS) code: 85176990
