Description
The Lian Li SP850WHITE power supply unit, in a black finish, offers a total output of 850 W with an SFX form factor designed for compact builds. Its efficiency reaches 93.53% and features active power factor correction, along with a universal input voltage of 100-240 V and a frequency of 50-60 Hz. The cabling is fully modular, including two SATA connectors, one Molex, two 6+2-pin PCI Express connectors, one 8-pin, a 4-pin CPU connector, and a 20-pin ATX power connector for the motherboard, with cable lengths of 30 cm (motherboard), 45 cm (CPU), and 40 cm (PCI Express). The combined power on the 12 V rail is 840 W, with 100 W on both the 5 V and 3.3 V rails, ensuring stable distribution for your system's components.
Specifications
Power
- Total power: 850 W
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
- Power Factor Correction (PFC) type: Active
- Combined power (+3.3V): 100 W
- Combined power (+12V): 840 W
- Combined power (+5V): 100 W
- Efficiency: 93.53%
Ports & interfaces
- Number of SATA power connectors: 2
- SATA power cable length: 120 mm
- Peripheral (Molex) power connectors (4-pin): 1
- Peripheral (Molex) power cable length: 120 mm
- PCI Express power connectors (6+2 pin): 2
- PCI Express power connectors (8-pin): 1
- PCI Express power cable length: 40 cm
- CPU P4 connector (4-pin): 1
- CPU power cable length: 45 cm
- Cabling type: Fully-Modular
- Motherboard power connector: 20-pin ATX
- Motherboard power cable length: 30 cm
Performance
- 80 PLUS certification: 80 PLUS Gold
- Supported motherboard form factors: ATX
- Purpose: PC
- Power supply unit (PSU) form factor: SFX
- Silent mode: Yes
- Noise level: 40.6 dB
- Bearing technology: FDB
Design
- Product colour: Black
- Fan speed: 1000 - 2800 RPM
Packaging content
- Cables included: CPU, PCIe, Peripheral (Molex), SATA
Safety regulation & standards
- Safety: OCP OVP OTP OPP SCP UVP
Weight & dimensions
- Width: 63.5 mm
- Depth: 100 mm
- Height: 125 mm
Logistics data
- Warranty period: 5 year(s)
