Description
Specifications
Power
- Total power: 650 W
- AC input voltage: 100 - 240 V
- AC input frequency: 50/60 Hz
- Input current: 10 A
- Power Factor Correction (PFC) type: Active
- Combined power (+3.3V): 100 W
- Combined power (+12V): 649.2 W
- Combined power (+5V): 100 W
- Combined power (-12V): 3.6 W
- Combined power (+5Vsb): 15 W
- Max output current (+3.3V): 20 A
- Max output current (+12V): 54.1 A
- Max output current (+5V): 20 A
- Max output current (-12V): 0.3 A
- Max output current (+5Vsb): 3 A
- Efficiency: 85%
- Power protection features: Over current, Over power, Over voltage, Short circuit, Under temperature, Under voltage
Ports & interfaces
- Motherboard power cable length: 60 cm
- Number of PATA power connectors: 3
- EPS power connector (8-pin): Yes
- EPS power connector (4+4 pin): Yes
- PCI Express power connectors (6+2 pin): 4
- CPU power connector (4+4 pin): Yes
- CPU power cable length: 65 cm
- ATX Power connector (24-pin): Yes
- Floppy drive power connector: 1
- Floppy disk drive connector: Yes
- Cabling type: Non-Modular
- Motherboard power connector: 24-pin ATX
Performance
- 80 PLUS certification: 80 PLUS Bronze
- Purpose: PC
- Power supply unit (PSU) form factor: ATX
- ATX version: 3.1
- Noise level: 39.3 dB
- Mean time between failures (MTBF): 100000 h
Design
- Product colour: Black
- Fan diameter: 13.5 cm
- Number of fans: 1 fan(s)
- Fan speed: 0 - 1600 RPM
Certificates
- Certification: CE/CB/cTUVus/TÜV/FCC/BSMI/CCC/KCC/SAA+RCM
Weight & dimensions
- Width: 86 mm
- Depth: 150 mm
- Height: 150 mm
