Description
Converts the copper link to fibre optic with the LevelOne GVT-2012, a Gigabit Ethernet media converter in a black finish that supports speeds of 10, 100 and 1000 Mbit/s. This unit handles jumbo frames up to 9000 bytes and features flow control, auto-negotiation and auto MDI/MDI-X for easy integration into your network. Its store-and-forward operation ensures reliable transfer, while the full or half duplex system adapts to your needs. Compliant with IEEE 802.3, 802.3ab, 802.3u, 802.3x and 802.3z standards, its input interface is 10Base-T, 100Base-TX and 1000Base-T, and the output is via 1000Base-LX or 1000Base-SX fibre.
Specifications
Network
- Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
- Fiber ethernet cabling technology: 1000BASE‑LX, 1000BASE‑SX
- Jumbo frames support: Yes
- Jumbo frames: 9000
- Flow control support: Yes
- Auto MDI/MDI-X: Yes
- Auto-negotiation: Yes
- Store-and-forward: Yes
- Duplex system: Full, Half
- Maximum data transfer rate: 1000 Mbit/s
- Converter input interface: 10Base-T, 100Base-TX, 1000Base-T
- Converter output interface: 1000Base-LX, 1000Base-SX
- Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
- Ethernet interface type: Gigabit Ethernet
- Ethernet LAN data rates: 10, 100, 1000 Mbit/s
Performance
- Mean time between failures (MTBF): 30000 h
Features
- Internal: No
- LED indicators: Yes
- Product colour: Black
Ports & interfaces
- Connectivity technology: Wired
- Ethernet LAN (RJ-45) ports: 1
- Fiber ports quantity: 1
- Fiber optic connector: SFP
- Power over Ethernet plus (PoE+) ports quantity: 1
- DC-in jack: Yes
Power
- Input voltage: 48 - 57 V
- Input current: 1 A
- Output voltage: 48 V
- Power over Ethernet (PoE): Yes
Weight & dimensions
- Width: 70 mm
- Depth: 94 mm
- Height: 26 mm
- Weight: 200 g
Operational conditions
- Operating temperature (T-T): -10 - 60 °C
- Storage temperature (T-T): -40 - 85 °C
- Operating relative humidity (H-H): 5 - 90%
Packaging content
- AC adapter included: Yes
- Quick installation guide: Yes
Packaging data
- Package width: 230 mm
- Package depth: 195 mm
- Package height: 70 mm
- Package weight: 500 g
- Package type: Box
Certificates
- Compliance certificates: RoHS
- Certification: CE, RoHS
Logistics data
- Country of origin: China
- Harmonized System (HS) code: 85176990
- Master (outer) case width: 420 mm
- Master (outer) case length: 440 mm
- Master (outer) case height: 367 mm
- Master (outer) case gross weight: 13 kg
- Products per master (outer) case: 20 pc(s)
