LevelOne 50-Port Fast Ethernet Switch, 2 x Gigabit SFP/RJ45 Combo

Product 1 image

Product 2 image

Product 3 image

LevelOne 50-Port Fast Ethernet Switch, 2 x Gigabit SFP/RJ45 Combo

226.00 €

186.78 € without VAT

Amount

Brand: LEVELONE

SKU: 80566 PRC: 206782 EAN: 4015867198407 PN: FGU-5021

Description

Specifications

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 50
Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100)
Fast Ethernet (copper) ports quantity: 48
Gigabit Ethernet (copper) ports quantity: 2
Combo SFP ports quantity: 2
Fiber optic connector: SFP
Console port: RJ-45

Network

Networking standards: IEEE 802.3, IEEE 802.3az, IEEE 802.3u
10G support: No
Copper ethernet cabling technology: 10BASE-T, 100BASE-T, 1000BASE-T, 1000BASE-TX
Full duplex: Yes
Auto MDI/MDI-X: Yes
Auto-negotiation: Yes
MAC address auto-learning supported: Yes
MAC address auto-aging supported: Yes

Optical fiber

Fiber ethernet cabling technology: 100BASE-X, 1000BASE-X

Data transmission

Switching capacity: 13.6 Gbit/s
MAC address table: 8000 entries
Store-and-forward: Yes
Jumbo frames support: Yes
Jumbo frames: 9000
Packet buffer memory: 4 MB

Design

Rack mounting: Yes
Product colour: Grey
Housing material: Metal
LED indicators: Activity, Link, Power

Performance

Internal memory: 16 MB

Power

Power supply included: Yes
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Power consumption (typical): 28.6 W

Power over Ethernet (PoE)

Power over Ethernet (PoE): No

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 90%

Weight & dimensions

Width: 44 mm
Depth: 230 mm
Height: 440 mm
Weight: 2.7 kg

Packaging content

Cables included: AC
Quick start guide: Yes

Packaging data

Package type: Gift box
Package width: 375 mm
Package depth: 100 mm
Package height: 510 mm
Package weight: 2.82 kg

Certificates

Certification: CE/FCC

Logistics data

Country of origin: China
Master (outer) case width: 520 mm
Master (outer) case length: 395 mm
Master (outer) case height: 535 mm
Harmonized System (HS) code: 85176990
Master (outer) case gross weight: 13.8 kg
Products per master (outer) case: 5 pc(s)
