Description
Specifications
Management features
- Switch type: Managed
- Switch layer: L2
- Quality of Service (QoS) support: Yes
- Web-based management: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 48
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- SFP+ module slots quantity: 4
Network
- Networking standards: IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3
- 10G support: Yes
- Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
- Full duplex: Yes
- Flow control support: Yes
- Link aggregation: Yes
- Rate limiting: Yes
- Auto MDI/MDI-X: Yes
- Spanning tree protocol: Yes
- VLAN support: Yes
Data transmission
- Switching capacity: 176 Gbit/s
- Throughput: 112 Mpps
- MAC address table: 16384 entries
- Latency (1 Gbps): 3.8 µs
- Latency (10 Gbps): 1.6 µs
- Jumbo frames support: Yes
Security
- DHCP features: DHCP server
- Access Control List (ACL): Yes
- SSH/SSL support: Yes
Design
- Rack mounting: Yes
- Form factor: 1U
- Product colour: Grey
- Airflow direction: Side-to-side airflow
Performance
- Built-in processor: Yes
- Processor model: ARM Cortex-A9
- Processor frequency: 1016 MHz
- Memory type: DDR3-SDRAM
- Internal memory: 1024 MB
- Flash memory: 4096 MB
Power
- Power source: AC
- Power supply included: Yes
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
- Power consumption (max): 459 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): Yes
- Total Power over Ethernet (PoE) budget: 370 W
Operational conditions
- Operating temperature (T-T): 0 - 45 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 15 - 95%
- Storage relative humidity (H-H): 15 - 95%
- Heat dissipation: 1566 BTU/h
Weight & dimensions
- Width: 442.5 mm
- Depth: 304.2 mm
- Height: 43.9 mm
- Weight: 4.46 kg
Logistics data
- Harmonized System (HS) code: 85176990
