Description
The Hiditec BZ550 v2 power supply, with 80PLUS BRONZE certification and 550 W, features an active power factor that optimises power delivery to your system. Its cable configuration includes a main 20+4 pin ATX connector, two EPS connectors, four PCI Express connectors in 6+2 pin format, and five SATA, along with two PATA and one for a floppy drive. It provides protection against overcurrent, overvoltage, short circuit, surge, undervoltage, and overheating, with a maximum current of 45 A on the +12V line. Suitable for mid-range builds, it offers stable power delivery for conventional components.
Specifications
Power
- Max output current (+3.3V): 20 A
- Max output current (+12V): 45 A
- Max output current (+5V): 20 A
- Max output current (-12V): 0.3 A
- Max output current (+5Vsb): 2.5 A
- Power protection features: Over current, Over voltage, Short circuit, Over power, Under voltage, Overheating
- Total power: 550 W
- AC input voltage: 230 V
- Input current: 5 A
- Power factor: 0.9
- Power Factor Correction (PFC) type: Active
Ports & interfaces
- Motherboard power connector: 20+4 pin ATX
- Motherboard power cable length: 60 cm
- Number of SATA power connectors: 5
- Number of PATA power connectors: 2
- SATA power cable length: 500, 630, 760, 890 mm
- EPS power connector (4+4 pin): Yes
- PCI Express power connectors (6+2 pin): 4
- ATX power connector (20+4 pin): Yes
- Floppy drive power connector: 1
- Floppy disk drive connector: Yes
- PCI Express connector: Yes
- Number of EPS connectors: 2
Performance
- 80 PLUS certification: 80 PLUS Bronze
- Purpose: PC
- Power supply unit (PSU) form factor: ATX
- Bearing technology: FDB
- Mean time between failures (MTBF): 100000 h
Design
- Product colour: Black
- Cooling type: Active
- Fan diameter: 14 cm
- Number of fans: 1 fan(s)
- On/off switch: Yes
Certificates
- Compliance certificates: CE, Federal Communications Commission (FCC), RoHS, CB
Weight & dimensions
- Width: 150 mm
- Depth: 160 mm
- Height: 86 mm
