Description
UNYKAch UK210551 power supply unit in ATX format with 550 W of power, finished in black and red, designed for desktop builds requiring a stable supply. It offers a main 20+4 pin ATX connector for the motherboard, plus a 4+4 pin EPS connector, five SATA connectors, three Molex and one 6+2 pin PCI Express for graphics cards. It includes protection against overcurrent, overvoltage, overtemperature, overload, short circuit and undervoltage, with passive power factor correction and a fan with FDB bearing. It operates on a 230 V input at 50 Hz, delivering up to 40 A on the +12V line, 14 A on +5V and 13 A on +3.3V, with auxiliary currents of 2 A on +5Vsb and 0.5 A on -12V.
Specifications
Power
- Total power: 550 W
- AC input voltage: 230 V
- AC input frequency: 50 Hz
- Power Factor Correction (PFC) type: Passive
- Max output current (+3.3V): 13 A
- Max output current (+12V): 40 A
- Max output current (+5V): 14 A
- Max output current (-12V): 0.5 A
- Max output current (+5Vsb): 2 A
- Power protection features: Over current, Over power, Over voltage, Overheating, Overload, Short circuit, Under voltage
Ports & interfaces
- Motherboard power connector: 20+4 pin ATX
- Number of SATA power connectors: 5
- Peripheral (Molex) power connectors (4-pin): 3
- EPS power connector (4+4 pin): Yes
- PCI Express power connectors (6+2 pin): 1
- Floppy disk drive connector: Yes
Performance
- Purpose: PC
- Power supply unit (PSU) form factor: ATX
- ATX version: 2.31
- Noise level: 28 dB
- Bearing technology: FDB
Design
- Product colour: Black, Red
- Cooling type: Active
- Fan diameter: 14 cm
- Number of fans: 1 fan(s)
- On/off switch: Yes
Packaging content
- Cables included: AC
Certificates
- Compliance certificates: CE, RoHS, TÜV mark
Weight & dimensions
- Width: 150 mm
- Depth: 160 mm
- Height: 85 mm
- Weight: 1.4 kg
Packaging data
- Manual: Yes
- Package width: 165 mm
- Package depth: 255 mm
- Package height: 95 mm
- Package weight: 1.7 kg
Other features
- Screws included: Yes
- Package volume: 4000 cm³
