Description
The Eaton 5PX1500IRT2UG2 UPS, with line-interactive topology, delivers an output power of 1500 W (1.5 kVA) and features 8 C13 AC outlets to protect your IT equipment. It accepts an input voltage of 160 V to 294 V and a frequency of 47/70 Hz, providing a pure sine wave that ensures stable power for your sensitive loads. It includes an RS-232 serial interface and USB port for monitoring, as well as hot-swap batteries and automatic battery testing. With a noise level of 40 dB, it includes protection against excessive discharge and the input connector is a C14 coupler to maintain the operational continuity of your devices.
Specifications
Features
- UPS topology: Line-Interactive
- Output power capacity: 1.5 kVA
- Output power: 1500 W
- Waveform: Pure sine
- Input operation voltage (min): 160 V
- Input operation voltage (max): 294 V
- Input frequency: 47/70 Hz
- Noise level: 40 dB
- Power protection features: Overdischarge
Ports & interfaces
- AC outlet types: C13 coupler
- Power plug: C14 coupler
- AC outlets quantity: 8 AC outlet(s)
- USB port: Yes
- Serial interface: Yes
- Serial interface type: RS-232
- Serial ports quantity: 1
Battery
- Hot-swap battery: Yes
- Automatic battery test: Yes
Design
- Form factor: Rackmount/Tower
- Rack capacity: 2U
- Product colour: Black
- Display type: LCD
- LED indicators: Yes
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
Certificates
- Compliance certificates: CE
- Certification: IEC/EN 62040-2, FCC B, CISPR22 B CB (TUV) / cTUVus / EAC / UKCA / Ukr / Cm
Safety regulation & standards
- Safety: IEC/EN 62040-1, UL1778, CSA22.2
Sustainability
- Sustainability compliance: Yes
- Sustainability certificates: ENERGY STAR
Weight & dimensions
- Width: 438 mm
- Depth: 448 mm
- Height: 85.5 mm
- Weight: 22.4 kg
Packaging data
- Management card included: No
Logistics data
- Harmonized System (HS) code: 85078000
Other features
- Nominal output voltage: 230 V
