Description
Specifications
Management features
- Switch type: Managed
- Switch layer: L3
- Quality of Service (QoS) support: Yes
- Web-based management: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 20
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- Combo SFP ports quantity: 4
- SFP+ module slots quantity: 4
- Fiber optic connector: SFP+
- Console port: RJ-45/Mini-USB
- USB 2.0 ports quantity: 1
Network
- Networking standards: IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Qbb, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 8
- 10G support: Yes
- Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
- Port mirroring: Yes
- Full duplex: Yes
- IP routing: Yes
- Routing entries: 16000
- Flow control support: Yes
- Link aggregation: Yes
- Head-of-line (HOL) blocking: Yes
- Auto-negotiation: Yes
- Ethernet Ring Protection Switching (ERPS): Yes
- VLAN support: Yes
- Virtual LAN features: Private VLAN, Voice VLAN, Protocol-based VLAN, MAC address-based VLAN, Port-based VLAN
- Number of VLANs: 4000
Data transmission
- Switching capacity: 128 Gbit/s
- Forwarding rate: 95.24 Mpps
- MAC address table: 68000 entries
- Store-and-forward: Yes
- Static route: Yes
- Number of static routes: 512
- Jumbo frames support: Yes
- Jumbo frames: 12000
- Packet buffer memory: 4 MB
Security
- DHCP features: DHCP server, DHCP client
- Access Control List (ACL): Yes
- IGMP snooping: Yes
- Security algorithms: 802.1x RADIUS, SNMP, SNMPv3, SSH, SSL/TLS
- SSH/SSL support: Yes
- Loop protection: Yes
- BPDU filtering/protection: Yes
- IP-MAC-Port binding: Yes
Multicast features
- Multicast support: Yes
- Multicast Listener Discovery (MLD) snooping: MLD v1, MLD v2
Design
- Rack mounting: Yes
- Stackable: Yes
- Product colour: Black, Grey
- Number of fans: 4 fan(s)
- Safety: cUL, CB, CE, CCC, BSMI
- Electromagnetic compatibility: CE, FCC A, C-Tick, VCCI, BSMI, CCC
Performance
- Physical stacking (units): 9
- Virtual stacking (units): 32
- Built-in processor: Yes
Power
- Redundant power supply (RPS) support: Yes
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
Power over Ethernet (PoE)
- Power over Ethernet (PoE): Yes
- Power over Ethernet plus (PoE+) ports quantity: 24
- Power over Ethernet (PoE) power per port: 30 W
- Total Power over Ethernet (PoE) budget: 370 W
Operational conditions
- Operating temperature (T-T): -5 - 50 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 10 - 95%
- Storage relative humidity (H-H): 5 - 95%
Weight & dimensions
- Width: 441 mm
- Depth: 380 mm
- Height: 44 mm
- Weight: 5.88 kg
Packaging data
- Package width: 538 mm
- Package depth: 560 mm
- Package height: 170 mm
- Package weight: 8.24 kg
Technical details
- Shipping (inner) case height: 57.2 cm
- Shipping (inner) case width: 36.2 cm
- Shipping (inner) case length: 57.9 cm
- Shipping (inner) case net weight: 12.9 kg
- Products per shipping (inner) case: 2 pc(s)
- Pallet gross weight (air): 342.4 kg
- Master (outer) cases per pallet (air): 18 pc(s)
- Products per pallet (air): 36 pc(s)
- Pallet gross length: 110 cm
- Pallet gross width: 120 cm
- Pallet height (air): 185.1 cm
- Pallet gross weight (sea): 342.4 kg
- Master (outer) cases per pallet (sea): 18 pc(s)
- Products per pallet (sea): 36 pc(s)
- Pallet height (sea): 185.1 cm
- Shipping (inner) case gross weight: 18 kg
Logistics data
- Harmonized System (HS) code: 85176990
