Description
The D-Link DGS-1005D switch is a black device designed to expand the local network with wired connections. It is an unmanaged Layer 2 switch, so it works without configuration and is suitable for home environments or small offices. It features five Gigabit Ethernet RJ-45 ports (10/100/1000) that allow several devices to be connected and reach transfer speeds of 10, 100 and 1000 Mbit/s. It supports full duplex and auto MDI/MDI-X, as well as the IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az and IEEE 802.3u standards. It offers a switching capacity of 10 Gbit/s and a MAC address table of 2000 entries with auto-learning. Store and forward, 9216 Jumbo frames and QoS support contribute to smooth traffic. With dimensions of 111 x 30 x 75 mm and a weight of 80 g, it is compact and easy to place.
Specifications
Management features
- Switch type: Unmanaged
- Switch layer: L2
- Quality of Service (QoS) support: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 5
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Network
- Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u
- 10G support: No
- Full duplex: Yes
- Auto MDI/MDI-X: Yes
- Ethernet LAN data rates: 10,100,1000 Mbit/s
- MAC address auto-learning supported: Yes
Data transmission
- Switching capacity: 10 Gbit/s
- MAC address table: 2000 entries
- Store-and-forward: Yes
- Jumbo frames support: Yes
- Jumbo frames: 9216
- Packet forwarding rate (1 Gbps): 1488000 pps
- Packet forwarding rate (100 Mbps): 148800 pps
- Packet forwarding rate (10 Mbps): 14880 pps
- Packet buffer memory: 0.128 MB
Design
- Rack mounting: No
- Product colour: Black
- Housing material: Plastic
- LED indicators: Yes
Performance
- Mean time between failures (MTBF): 1142330 h
Power
- DC input voltage: 5 V
- Input current: 1 A
- Power consumption (max): 2.01 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): No
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -10 - 70 °C
- Operating relative humidity (H-H): 10 - 90%
- Storage relative humidity (H-H): 5 - 90%
Weight & dimensions
- Width: 111 mm
- Depth: 75 mm
- Height: 30 mm
- Weight: 80 g
Packaging content
- Manual: Yes
Logistics data
- Harmonized System (HS) code: 85176990
