Name: D-Link 28-Port Gigabit Stackable PoE Smart Managed Switch including 2 x 10G SFP+ & 2 x SFP
Brand: D-LINK
Price: 704.61 USD
Availability: InStock

D-Link 28-Port Gigabit Stackable PoE Smart Managed Switch including 2 x 10G SFP+ & 2 x SFP

$704.61

$704.61 without VAT

D-Link 28-Port Gigabit Stackable PoE Smart Managed Switch including 2 x 10G SFP+ & 2 x SFP. More info

Amount

Brand: D-LINK

SKU: 71994 PRC: 33163 EAN: 7900693994736 PN: DGS-1510-28P

Description

Specifications

Management features

Switch type: Managed
Switch layer: L3
Quality of Service (QoS) support: Yes
Web-based management: Yes
System event log: Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 24
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
SFP module slots quantity: 2
SFP+ module slots quantity: 2
Power connector: DC-in jack

Network

Networking standards: IEEE 802.1D, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3
10G support: Yes
Cable types supported: Cat5, Cat5e
Port mirroring: Yes
Full duplex: Yes
Flow control support: Yes
Link aggregation: Yes
Broadcast storm control: Yes
Auto MDI/MDI-X: Yes
Head-of-line (HOL) blocking: Yes
Auto-negotiation: Yes
MAC address auto-learning supported: Yes
VLAN support: Yes

Data transmission

Switching capacity: 92 Gbit/s
Forwarding rate: 68.45 Mpps
MAC address table: 16000 entries
Store-and-forward: Yes
Number of static routes: 512
Jumbo frames support: Yes
Packet buffer memory: 1.5 MB

Security

DHCP features: DHCP server, DHCP client
Access Control List (ACL): Yes
IGMP snooping: Yes
MAC address filtering: Yes
Static port security: Yes
SSH/SSL support: Yes

Multicast features

Multicast support: Yes

Design

Rack mounting: Yes
Stackable: Yes
Product colour: Black
LED indicators: Activity, Link, PoE, Power
Number of fans: 2 fan(s)
Safety: cUL, CB

Performance

Physical stacking (units): 6
Virtual stacking (units): 32
Noise level: 46.4 dB

Power

AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Power consumption (typical): 238.7 W

Power over Ethernet (PoE)

Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) ports quantity: 24
Total Power over Ethernet (PoE) budget: 193 W

Operational conditions

Operating temperature (T-T): -5 - 50 °C
Storage temperature (T-T): -20 - 70 °C
Operating relative humidity (H-H): 0 - 95%
Storage relative humidity (H-H): 0 - 95%
Heat dissipation: 813.967 BTU/h

Weight & dimensions

Width: 440 mm
Depth: 250 mm
Height: 44 mm
Weight: 2.54 kg

Packaging content

Manual: Yes

Packaging data

Package width: 348 mm
Package depth: 511 mm
Package height: 91 mm
Package weight: 4 kg

Technical details

Shipping (inner) case height: 38.3 cm
Shipping (inner) case width: 29.6 cm
Shipping (inner) case length: 52.9 cm
Shipping (inner) case net weight: 9.27 kg
Products per shipping (inner) case: 3 pc(s)
Pallet gross weight (air): 533.9 kg
Master (outer) cases per pallet (air): 40 pc(s)
Products per pallet (air): 120 pc(s)
Pallet gross length: 110 cm
Pallet gross width: 120 cm
Pallet height (air): 2.05 m
Pallet gross weight (sea): 533.9 kg
Master (outer) cases per pallet (sea): 40 pc(s)
Products per pallet (sea): 120 pc(s)
Pallet height (sea): 2.05 m
Shipping (inner) case gross weight: 12.9 kg

Certificates

Certification: CE, FCC, C-Tick, VCCI, BSMI, CCC

Logistics data

Harmonized System (HS) code: 85176990
