Name: Zyxel XGS1930-28HP Managed L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
Brand: ZYXEL
Price: 529.41 USD
Availability: InStock

Zyxel XGS1930-28HP Managed L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black

$529.41

$529.41 without VAT

Zyxel XGS1930-28HP Managed L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black. More info

Amount

Brand: ZYXEL

SKU: 81231 PRC: 235983 EAN: 4718937595006 PN: XGS1930-28HP-EU0101F

Description

Specifications

Management features

Switch type: Managed
Switch layer: L3
Quality of Service (QoS) support: Yes
Web-based management: Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 24
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
SFP+ module slots quantity: 4
Fiber optic connector: SFP+

Network

Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3
10G support: Yes
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
Port mirroring: Yes
IP routing: Yes
Routing entries: 32
Flow control support: Yes
Link aggregation: Yes
Broadcast storm control: Yes
Spanning tree protocol: Yes
VLAN support: Yes
Virtual LAN features: Voice VLAN, Port-based VLAN
Number of VLANs: 4000

Data transmission

Switching capacity: 128 Gbit/s
Forwarding rate: 95.2 Mpps
MAC address table: 16000 entries
Static route: Yes
Path MTU discovery: Yes
Packet buffer memory: 1.5 MB

Security

DHCP features: DHCP relay, DHCPv6 relay, DHCP client
Access Control List (ACL): Yes
IGMP snooping: Yes
Security algorithms: 802.1x RADIUS, HTTPS, SHA-2, SNMPv3, SSL/TLS
SSH/SSL support: Yes
Loop protection: Yes
Authentication: Guest VLAN, MAC-based authentication, Port-based authentication
Password protection: Yes
CPU defense: Yes

Multicast features

Multicast support: Yes

Protocols

GARP VLAN Registration Protocol (GVRP): Yes

Design

Rack mounting: Yes
Product colour: Black
Safety: LVD, BSMI
Electromagnetic compatibility: FCC 15 A, CE A, BSMI EMC

Performance

Internal memory: 512 MB
Flash memory: 32 MB
Noise level: 28.5 dB
Mean time between failures (MTBF): 1369432 h

Power

AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Power consumption (max): 471 W

Power over Ethernet (PoE)

Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) ports quantity: 24
Total Power over Ethernet (PoE) budget: 375 W

Operational conditions

Operating temperature (T-T): 0 - 50 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 10 - 95%
Storage relative humidity (H-H): 10 - 95%
Heat dissipation: 1606.11 BTU/h

Weight & dimensions

Width: 441 mm
Depth: 330 mm
Height: 44 mm
Weight: 4.6 kg

Packaging content

Cables included: AC
Rack mount kit: Yes

Packaging data

Package width: 585 mm
Package depth: 503 mm
Package height: 95 mm
Package weight: 5.82 kg

Certificates

Certification: RoHS

Logistics data

Harmonized System (HS) code: 85176990
