Description
Connect up to 24 devices with this TP-Link unmanaged Gigabit Ethernet switch, in a black finish, operating at 10/100/1000 Mbps for smooth network transfers. Its 48 Gbit/s switching capacity and MAC address table with 8000 entries manage traffic efficiently, while support for jumbo frames of 10000 bytes optimises data transmission. It includes auto-negotiation and auto MDI/MDI-X to simplify installation, as no prior configuration is required. Additionally, its fanless design ensures silent and reliable operation in home or small office environments, with store-and-forward to maintain packet integrity.
Specifications
Management features
- Switch type: Unmanaged
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 24
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Network
- Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3p, IEEE 802.3u, IEEE 802.3x
- 10G support: No
- Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
- Auto MDI/MDI-X: Yes
- Auto-negotiation: Yes
Data transmission
- Switching capacity: 48 Gbit/s
- Forwarding rate: 35.712 Mpps
- MAC address table: 8000 entries
- Store-and-forward: Yes
- Jumbo frames support: Yes
- Jumbo frames: 10000
- Packet buffer memory: 2 MB
Design
- Rack mounting: No
- Product colour: Black
Performance
- Fanless: Yes
- Mean time between failures (MTBF): 1183684 h
Power
- Power source: AC
- Power supply included: Yes
- AC input voltage: 100 - 240 V
- AC input frequency: 50/60 Hz
- Input current: 0.6 A
- Power consumption (max): 12.6 W
Operational conditions
- Storage relative humidity (H-H): 5 - 90%
- Heat dissipation: 42.77 BTU/h
- Operating temperature (T-T): 0 - 45 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 10 - 90%
Weight & dimensions
- Width: 294 mm
- Depth: 140 mm
- Height: 44 mm
Packaging content
- Cables included: Power
- User guide: Yes
- Rack mount kit: Yes
Certificates
- Compliance certificates: CE, Federal Communications Commission (FCC), RoHS
