Name: Synology DiskStation DS1522+ NAS/storage server Tower AMD Embedded R-Series SoC R1600 8 GB DDR4 0 TB DiskStation Manager Black
Brand: SYNOLOGY
Price: 771.26 USD
Availability: InStock

Synology DiskStation DS1522+ NAS/storage server Tower AMD Embedded R-Series SoC R1600 8 GB DDR4 0 TB DiskStation Manager Black

$771.26

$771.26 without VAT

Amount

Brand: SYNOLOGY

SKU: 94194 PRC: 376445 EAN: 4711174724468 PN: DS1522+

Description

Specifications

Storage

Supported storage drive interfaces: Serial ATA II, Serial ATA III
Storage drive sizes supported: 2.5, 3.5, M.2
Number of M.2 (M & B) slots: 2
RAID support: Yes
RAID levels: 0, 1, 5, 6, 10, JBOD
Online RAID migration: Yes
Online RAID expansion: Yes
Hot-swap drive bays: Yes
Supported file systems: BTRFS, Fat, HFS+, NTFS, exFAT, ext3, ext4
Storage drives installed: No
Total installed storage capacity: 0 TB
Number of storage drives supported: 5
Installed storage drive type: No
Supported storage drive types: HDD & SSD

Processor

Processor manufacturer: AMD
Processor family: AMD Embedded R-Series SoC
Processor model: R1600
Processor frequency: 2.6 GHz
Processor boost frequency: 3.1 GHz
Processor cores: 2

Memory

Internal memory: 8 GB
Internal memory type: DDR4
Maximum RAM supported: 32 GB
Memory slots: 2
Memory form factor: SO-DIMM
ECC: Yes

Network

Ethernet LAN: Yes
Ethernet LAN data rates: 10, 100, 1000 Mbit/s
Ethernet LAN data rate supported (max): 10000 Mbit/s
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
iSCSI support: Yes
Wake-on-LAN ready: Yes
Supported network protocols: SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV
Link aggregation: Yes

Ports & interfaces

USB port: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
eSATA ports quantity: 2
Ethernet LAN (RJ-45) ports: 4

Design

Chassis type: Tower
Cooling type: Active
Product colour: Black
Number of fans: 2 fan(s)
Fan diameter: 9.2 cm
Drive bay locking: Yes
LED indicators: Yes
Built-in display: No
Cable lock slot: Yes
Cable lock slot type: Kensington

Performance

Type: NAS
Device class: Home & Home Office
Backup function: Yes
Backup features: Cloud, iSCSI LUN
Multilingual support: Yes
Number of users: 2048 user(s)
Noise level: 22.9 dB
Video input channels: 2 channels
Card reader integrated: No
Snapshot: Yes
Management protocols: SNMP
Web-based management: Yes
Security algorithms: HTTPS
Access Control List (ACL): Yes
Reset button: Yes
On/off switch: Yes
Built-in UPnP AV media server: Yes
Browser supported: Google Chrome, Firefox, Microsoft Edge, Safari
Hot spare: Yes

Software

Operating system installed: DiskStation Manager
Operating system version: 7.1
Windows operating systems supported: Yes

Power

Power supply location: External
Power supply unit (PSU) capacity: 120 W
Number of power supply units: 1
Redundant power supply (RPS) support: No
Power consumption (typical): 52.06 W
Power consumption (HDD standby): 16.71 W
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz

Weight & dimensions

Width: 230 mm
Depth: 223 mm
Height: 166 mm
Weight: 2.7 kg

Packaging content

External power adapter: Yes
Cables included: AC, LAN (RJ-45)
Power cables quantity: 1
Remote control included: No

Sustainability

Sustainability compliance: Yes

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -20 - 60 °C

Logistics data

Harmonized System (HS) code: 84714100

Other features

Compliance certificates: RoHS
Certification: FCC BSMI VCCI RCM UKCA EAC CCC KC
