Description
Synology RackStation RS422+ NAS/storage server in 1U rack form factor, equipped with a dual-core AMD Ryzen Embedded R1600 processor and 2 GB DDR4 memory, finished in black. This model supports up to four 2.5" or 3.5" SATA storage drives, both HDD and SSD, with hot-swap bays for replacing drives without interrupting service. It offers compatibility with RAID 0, 1, 5, 6, 10 and JBOD levels, and supports multiple file systems such as BTRFS, ext4 or NTFS, facilitating data management in professional environments. Its 2.6 GHz processor with four threads provides balanced performance for network storage, backup and file access tasks.
Specifications
Storage
- Supported storage drive interfaces: Serial ATA
- Storage drive sizes supported: 2.5, 3.5"
- RAID support: Yes
- RAID levels: 0, 1, 5, 6, 10, JBOD
- Hot-swap drive bays: Yes
- Supported file systems: BTRFS, FAT32, HFS+, NTFS, exFAT, ext3, ext4
- Storage drives installed: No
- Number of storage drives supported: 4
- Installed storage drive type: No
- Supported storage drive types: HDD & SSD
Processor
- Processor manufacturer: AMD
- Processor generation: AMD Ryzen Embedded R1000 Series
- Processor family: Ryzen Embedded
- Processor model: R1600
- Processor frequency: 2.6 GHz
- Processor boost frequency: 3.1 GHz
- Processor cores: 2
- Processor threads: 4
- On-board graphics card model: Not available
Memory
- Internal memory: 2 GB
- Internal memory type: DDR4
- ECC: Yes
Network
- Ethernet LAN: Yes
- Ethernet LAN data rates: 1000 Mbit/s
- Wake-on-LAN ready: Yes
- Supported network protocols: SMB, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, and VPN (PPTP, OpenVPN, L2TP)
Ports & interfaces
- USB port: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
- Ethernet LAN (RJ-45) ports: 2
- Expansion ports quantity: 1
Design
- Chassis type: Rack (1U)
- Cooling type: Active
- Product colour: Black
- Number of fans: 3 fan(s)
- Fan diameter: 4 cm
- LED indicators: Yes
Performance
- Type: NAS
- Device class: Home & Home Office
- Backup function: Yes
- Number of users: 2048 user(s)
- Share folder access right management: Yes
- Access Control List (ACL): Yes
- Reset button: Yes
- On/off switch: Yes
- Browser supported: Google Chrome, Firefox, Microsoft Edge, Safari 13 and later, and Safari (iOS 13.0 and later) on iPad, Chrome (Android 11.0 and l
- Share folder: 1024
Software
- Operating system installed: DSM
- Operating system version: 7.1
Power
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
Weight & dimensions
- Width: 430.5 mm
- Depth: 295.5 mm
- Height: 44 mm
- Weight: 4.38 kg
Packaging content
- Cables included: AC
- Quick installation guide: Yes
- Rack mount kit: Yes
Operational conditions
- Operating temperature (T-T): 0 - 35 °C
- Operating relative humidity (H-H): 8 - 80%
- Storage temperature (T-T): -20 - 60 °C
- Storage relative humidity (H-H): 5 - 95%
- Operating altitude: 0 - 5000 m
Logistics data
- Harmonized System (HS) code: 84714100
Other features
- I/O ports: Console Port
- Compliance certificates: RoHS
