Description
The NOX GDX 850 power supply unit, in its 850 W black version, provides a combined power of 846 W on the +12 V rail with a maximum output current of 70.5 A, along with 110 W combined on the +3.3 V and +5 V rails. With active power factor correction (PFC) and 100-240 V AC input, this ATX unit features a 16-pin PCI Express power connector and three 6+2-pin connectors for graphics cards, as well as three 4-pin Molex connectors. Its maximum output currents include 20 A on +3.3 V and +5 V, 3 A on +5 VSB, and 0.3 A on -12 V, with an input frequency of 47-63 Hz. Connect this unit to power demanding configurations while maintaining a stable power distribution among the system's different rails.
Specifications
Power
- Total power: 850 W
- AC input voltage: 100 - 240 V
- AC input frequency: 47 - 63 Hz
- Input current: 10 A
- Power Factor Correction (PFC) type: Active
- Combined power (+3.3V): 110 W
- Combined power (+12V): 846 W
- Combined power (+5V): 110 W
- Combined power (-12V): 3.6 W
- Combined power (+5Vsb): 15 W
- Max output current (+3.3V): 20 A
- Max output current (+12V): 70.5 A
- Max output current (+5V): 20 A
- Max output current (-12V): 0.3 A
- Max output current (+5Vsb): 3 A
- Power protection features: No load operation, Over current, Over power, Over voltage, Overheating, Surge & inrush protection (SIP), Surge protection, Under
Ports & interfaces
- Motherboard power connector: 20+4 pin ATX
- Number of SATA power connectors: 4
- Peripheral (Molex) power connectors (4-pin): 3
- EPS power connector (4+4 pin): Yes
- PCI Express power connectors (6+2 pin): 3
- PCI Express power connectors (16-pin): 1
- ATX power connector (20+4 pin): Yes
- PCI Express connector: Yes
- Cabling type: Non-Modular
Performance
- 80 PLUS certification: 80 PLUS Gold
- Purpose: PC
- Power supply unit (PSU) form factor: ATX
- ATX version: 3.1
Design
- Product colour: Black
- Cooling type: Active
- Fan diameter: 12 cm
- Number of fans: 1 fan(s)
- Fan location: Top
- On/off switch: Yes
Weight & dimensions
- Width: 150 mm
- Depth: 140 mm
- Height: 86 mm
- Weight: 1.94 kg
Packaging data
- Package type: Box
