Name: NETGEAR GS516PP Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Blue, Grey
Brand: NETGEAR
Price: 330 EUR
Availability: InStock

NETGEAR GS516PP Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Blue, Grey

330.00 €

272.73 € without VAT

Amount

Brand: NETGEAR

SKU: 85359 PRC: 293733 EAN: 606449149258 PN: GS516PP-100EUS

Description

NETGEAR GS516PP, Unmanaged, Gigabit Ethernet (10/100/1000), Full duplex, Power over Ethernet (PoE), Rack mounting

Specifications

Management features

Switch type: Unmanaged
Quality of Service (QoS) support: Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 16
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)

Network

Networking standards: IEEE 802.3ab, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u
10G support: No
Copper ethernet cabling technology: 10GBASE-T, 100BASE-T, 1000BASE-T
Full duplex: Yes
Half duplex: Yes
Auto MDI/MDI-X: Yes

Data transmission

Switching capacity: 32 Gbit/s
MAC address table: 8000 entries
Latency (1 Gbps): 12 µs
Jumbo frames support: Yes
Jumbo frames: 9216
Packet forwarding rate (1 Gbps): 1448000 pps
Packet buffer memory: 0.192 MB

Security

Queue scheduling algorithms: Weighted Round Robin (WRR)

Design

Rack mounting: Yes
Product colour: Blue, Grey
Housing material: Metal
LED indicators: Activity, Fan fail, Link, PoE, Power, Speed
Number of fans: 2 fan(s)

Performance

Mean time between failures (MTBF): 2415333.9 h

Power

Power supply included: Yes
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Power consumption (max): 316.1 W

Power over Ethernet (PoE)

Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) type supported: PoE+
Power over Ethernet plus (PoE+) ports quantity: 16
Power over Ethernet (PoE) power per port: 30 W
Total Power over Ethernet (PoE) budget: 260 W

Operational conditions

Operating temperature (T-T): 0 - 50 °C
Storage temperature (T-T): -20 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 10 - 95%
Operating altitude: 0 - 3000 m

Weight & dimensions

Width: 330 mm
Depth: 207 mm
Height: 43 mm
Weight: 2.3 kg

Certificates

Certification: FCC 47 CFR Part15B (Class A) ICES-003 Class A EN 55024/55032/55035 (Class A) AS/NZS CISPR 32 VCCI BSMI CNS13438 KCC UL 62368-1

Logistics data

Harmonized System (HS) code: 85176990
