Description
The NETGEAR GS108LP switch is an unmanaged device in black and grey that offers Gigabit Ethernet connectivity through its 8 RJ-45 ports, with transfer speeds of 10, 100 and 1000 Mbit/s. It incorporates an AC-in power connector and supports Quality of Service (QoS), flow control and store-and-forward. Its MAC address table supports 4000 entries and reaches a switching capacity of 16 Gbit/s, as well as being compatible with Jumbo Frames. It complies with network standards such as IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at and IEEE 802.3az. With a 1U form factor, it allows rack and wall mounting, and includes LED indicators to monitor its operation. Its dimensions are 236 x 27 x 102 mm (width x height x depth) and its weight is 600 g.
Specifications
Management features
- Switch type: Unmanaged
- Quality of Service (QoS) support: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- Gigabit Ethernet (copper) ports quantity: 8
- Power connector: AC-in jack
Network
- Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
- 10G support: No
- Flow control support: Yes
- Ethernet LAN data rates: 10,100,1000 Mbit/s
Data transmission
- Switching capacity: 16 Gbit/s
- MAC address table: 4000 entries
- Store-and-forward: Yes
- Jumbo frames support: Yes
Design
- Rack mounting: Yes
- Form factor: 1U
- Product colour: Black, Grey
- LED indicators: Yes
- Wall mountable: Yes
- Number of fans: 0 fan(s)
Performance
- Buffer size: 192 KB
- Plug and Play: Yes
- Mean time between failures (MTBF): 2752476 h
Power
- Power source: DC/PoE
- DC input voltage: 54 V
- Input current: 1.25 A
- Power consumption (typical): 67.5 W
- Power consumption (max): 130 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): Yes
- Power over Ethernet plus (PoE+) ports quantity: 8
- Total Power over Ethernet (PoE) budget: 60 W
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -20 - 70 °C
- Operating relative humidity (H-H): 0 - 90%
- Storage relative humidity (H-H): 0 - 95%
- Operating altitude: 0 - 1000 m
- Heat dissipation: 230.85 BTU/h
Weight & dimensions
- Width: 236 mm
- Depth: 102 mm
- Height: 27 mm
- Weight: 600 g
Logistics data
- Harmonized System (HS) code: 85176990
