Description
Connect your network with the NETGEAR GS316EP-100PES managed switch, a Gigabit Ethernet device with 15 RJ-45 ports that reaches a switching capacity of 32 Gbit/s. Its black colour and its dimensions of 286 x 27 x 102 mm (width x height x depth) allow it to be easily integrated into a rack or on a surface, with a weight of 883 g. It incorporates an SFP module slot to expand connection options and supports web-based management, which makes it easy to adjust parameters such as VLANs or QoS quality of service. It also offers flow control, storm transmission control and link aggregation, as well as operating in full duplex mode. It has support for Jumbo frames of up to 10000 and a MAC address table of 4000 entries, designed to manage the traffic of a network with multiple devices.
Specifications
Management features
- Switch type: Managed
- Quality of Service (QoS) support: Yes
- Web-based management: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 15
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- Gigabit Ethernet (copper) ports quantity: 15
- SFP module slots quantity: 1
- Power connector: DC-in jack
Network
- Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
- Full duplex: Yes
- Flow control support: Yes
- Link aggregation: Yes
- Broadcast storm control: Yes
- VLAN support: Yes
Data transmission
- Switching capacity: 32 Gbit/s
- MAC address table: 4000 entries
- Jumbo frames support: Yes
- Jumbo frames: 10000
Security
- DHCP features: DHCP client
- Access Control List (ACL): Yes
Multicast features
- Multicast support: Yes
Design
- Stackable: No
- Product colour: Black
- LED indicators: Yes
Power
- Power source: DC
- Power supply included: Yes
Power over Ethernet (PoE)
- Power over Ethernet (PoE): Yes
- Power over Ethernet (PoE) ports quantity: 15
- Total Power over Ethernet (PoE) budget: 180 W
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -20 - 70 °C
- Operating relative humidity (H-H): 0 - 90%
- Storage relative humidity (H-H): 0 - 95%
- Operating altitude: 0 - 3000 m
- Non-operating altitude: 0 - 3000 m
Weight & dimensions
- Width: 286 mm
- Depth: 102 mm
- Height: 27 mm
- Weight: 883 g
Packaging content
- Cables included: AC
Logistics data
- Harmonized System (HS) code: 85176990
