Name: NETGEAR GS108Tv3 Managed L2 Gigabit Ethernet (10/100/1000) Grey
Brand: NETGEAR
Price: 82 EUR
Availability: InStock

NETGEAR GS108Tv3 Managed L2 Gigabit Ethernet (10/100/1000) Grey

82.00 €

67.77 € without VAT

Amount

Brand: NETGEAR

SKU: 82972 PRC: 265237 EAN: 606449138634 PN: GS108T-300PES

Description

NETGEAR GS108Tv3, Managed, L2, Gigabit Ethernet (10/100/1000), Full duplex

Specifications

Management features

Switch type: Managed
Switch layer: L2
Quality of Service (QoS) support: Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 8
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Power connector: DC-in jack

Network

Networking standards: IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3x
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-TX
Port mirroring: Yes
Full duplex: Yes
Flow control support: Yes
Link aggregation: Yes
Broadcast storm control: Yes
Rate limiting: Yes
Spanning tree protocol: Yes
MAC address auto-learning supported: Yes
Number of VLANs: 64

Data transmission

Switching capacity: 16 Gbit/s
MAC address table: 8000 entries
Store-and-forward: Yes
Jumbo frames support: Yes
Packet buffer memory: 0.5 MB

Security

DHCP features: DHCP client
Access Control List (ACL): Yes
Access Control List (ACL) IPv6 entries: 100
IGMP snooping: Yes
Security algorithms: 802.1x RADIUS
MAC address filtering: Yes

Multicast features

Number of multicast groups filtered: 256
Multicast support: Yes
IPv4 multicast entries: 32

Protocols

Management protocols: SNMP
Switching protocols: SNMP
Data link protocols: Ethernet, Fast Ethernet, Gigabit Ethernet
Supported network protocols: HTTP, HTTPS

Design

Stackable: No
Product colour: Grey
LED indicators: Activity, LAN, Link, PoE, Power, Speed

Performance

Processor frequency: 500 MHz
Memory type: RAM
Internal memory: 128 MB
Flash memory: 32 MB
Firmware upgradeable: Yes
Mean time between failures (MTBF): 2388657 h

Power

Power supply included: Yes
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
DC input voltage: 54 V
Input current: 1.25 A
Power consumption (max): 5.5 W

Power over Ethernet (PoE)

Power over Ethernet (PoE): No

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -20 - 70 °C
Operating relative humidity (H-H): 0 - 95%
Storage relative humidity (H-H): 0 - 95%
Operating altitude: 0 - 3000 m
Non-operating altitude: 0 - 3000 m
Heat dissipation: 18.66 BTU/h

Weight & dimensions

Width: 158 mm
Depth: 101 mm
Height: 27 mm
Weight: 430 g

Packaging content

Manual: Yes

Packaging data

Package type: Box
Package width: 226 mm
Package depth: 270 mm
Package height: 64 mm
Package weight: 780 g

Certificates

Certification: CE, FCC, VCCI Class B, C-Tick

Logistics data

Master (outer) case width: 214 mm
Master (outer) case length: 474 mm
Master (outer) case height: 312 mm
Harmonized System (HS) code: 85176990
Master (outer) case gross weight: 5.49 kg
Products per master (outer) case: 6 pc(s)
